4–25Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 9
0960 Your entry combination as follows is illegal: IPC60 = IPC61 = IPC62 = IPC63 = 00000
1015 IPC15 is not in decreasing positional order
.
If non-zero, IPC15 must be less than IPC11.
1019 IPC19 is not in decreasing positional order.
If non-zero, IPC19 must be less than IPC15.
1023 IPC23 is not in decreasing positional order.
If non-zero, IPC23 must be less than IPC19.
1027 IPC27 is not in decreasing positional order.
If non-zero, IPC27 must be less than IPC23.
1031 IPC31 is not in decreasing positional order
.
If non-zero, IPC31 must be less than IPC27.
1035 IPC35 is not in decreasing positional order.
If non-zero, IPC35 must be less than IPC31.
1039 IPC39 is not in decreasing positional order.
If non-zero, IPC39 must be less than IPC35.
1043 IPC43 is not in decreasing positional order.
If non-zero, IPC43 must be less than IPC39.
1047 IPC47 is not in decreasing positional order.
If non-zero, IPC47 must be less than IPC43.
ID = 10
PKC – Pack Configuration Block
Error Code
Description
ID = 10
0205
PKC05 is out of range. Valid range is 00000
≤
PKC05
≤
09999
0206
PKC06 is out of range. Valid range is 00000
≤
PKC06
≤
09999
0209
PKC09 is out of range. Valid range is 00000
≤
PKC09
≤
09999
0210
PKC10 is out of range. Valid range is 00000
≤
PKC10
≤
09999
0211
PKC11 is out of range. Valid range is 00000
≤
PKC11
≤
09999
0212
PKC12 is out of range. Valid range is 00000
≤
PKC12
≤
09999
0213
PKC13 is out of range. Valid range is 00000
≤
PKC13
≤
09999
0214
PKC14 is out of range. Valid range is 00000
≤
PKC14
≤
09999
0215
PKC15 is out of range. Valid range is 00000
≤
PKC15
≤
09999
0216
PKC16 is out of range. Valid range is 00000
≤
PKC16
≤
09999
0217
PKC17 is out of range. Valid range is 00000
≤
PKC17
≤
09999
0218
PKC18 is out of range. Valid range is 00000
≤
PKC18
≤
09999
0219
PKC19 is out of range. Valid range is 00000
≤
PKC19
≤
09999
0220
PKC20 is out of range. Valid range is 00000
≤
PKC20
≤
09999
0221
PKC21 is out of range. Valid range is 00000
≤
PKC21
≤
09999
0222
PKC22 is out of range. Valid range is 00000
≤
PKC22
≤
09999
0223
PKC23 is out of range. Valid range is 00000
≤
PKC23
≤
09999
0224
PKC24 is out of range. Valid range is 00000
≤
PKC24
≤
09999
0225
PKC25 is out of range. Valid range is 00000
≤
PKC25
≤
09999
0226
PKC26 is out of range. Valid range is 00000
≤
PKC26
≤
09999
0227
PKC27 is out of range. Valid range is 00000
≤
PKC27
≤
09999
0228
PKC28 is out of range. Valid range is 00000
≤
PKC28
≤
09999
0229
PKC29 is out of range. Valid range is 00000
≤
PKC29
≤
09999
0230
PKC30 is out of range. Valid range is 00000
≤
PKC30
≤
09999
0231
PKC31 is out of range. Valid range is 00000
≤
PKC31
≤
09999
0232
PKC32 is out of range. Valid range is 00000
≤
PKC32
≤
09999
