User Manual

4–22 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 9
0443 IPC43 is out of range.
if: then:
MCC13 and MCC14 IPC43 must be within 00000 ≤ IPC43 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC43 must be within 00000 ≤ IPC43 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC43 must be within 00000 ≤ IPC43 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC43 must be within 00000 ≤ IPC43 ≤ MCC10 – MCC09
are both zero
0445 IPC45 is out of range.
When IPC03-B14 = 1, a non-zero IPC45 must be within INC45
≤ IPC45 ≤ INC46
0446 IPC46 is out of range.
If non-zero, IPC46 must be within INC41
≤ IPC46 ≤ INC42
0447 IPC47 is out of range.
if: then:
MCC13 and MCC14 IPC47 must be within 00000 ≤ IPC47 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC47 must be within 00000 ≤ IPC47 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC47 must be within 00000 ≤ IPC47 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC47 must be within 00000 ≤ IPC47 ≤ MCC10 – MCC09
are both zero
0449 IPC49 is out of range.
When IPC03-B14 = 1, a non-zero IPC49 must be within INC45
≤ IPC49 ≤ INC46
0450 IPC50 is out of range.
If non-zero, IPC50 must be within INC41
≤ IPC50 ≤ INC42
0451 IPC51 is out of range.
When IPC03-B14 = 1, IPC51 must be within 00000
≤ IPC51 ≤ INC46
0452
IPC52 is out of range. Valid range is 00000 ≤ IPC52 ≤ INC42
0457 You have selected Pressure Limited Vel/Pos execution for the Injection Profile by
IPC03-B01 = 0 and IPC03-B00 = 1; however
,
IPC03
-
B01
=
0
and
IPC03
-
B00
=
1
;
ho
w
e
v
er
,
IPC57 is out of range. IPC57 must be within MCC17 < IPC57
≤ MCC18
0458 You have selected Pressure Limited Vel/Pos execution for the Injection Profile by
IPC03-B01 = 0 and IPC03-B00 = 1.
IPC58 is out of range.
if: then:
MCC13 and MCC14 IPC58 must be within 00000 ≤ IPC58 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC58 must be within 00000 ≤ IPC58 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC58 must be within 00000 ≤ IPC58 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC58 must be within 00000 ≤ IPC58 ≤ MCC10 – MCC09
are both zero
