User Manual

4–21Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description ID = 9
0429 IPC29 is out of range.
When IPC03-B14 = 1, a non-zero IPC29 must be within INC45
≤ IPC29 ≤ INC46
0430 IPC30 is out of range.
If non-zero, IPC30 must be within INC41
≤ IPC30 ≤ INC42
0431 IPC31 is out of range.
if: then:
MCC13 and MCC14 IPC31 must be within 00000 ≤ IPC31 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC31 must be within 00000 ≤ IPC31 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC31 must be within 00000 ≤ IPC31 ≤ MCC14 – MCC09
MCC14 is non-zero .
If MCC13 and MCC14 IPC31 must be within 00000 ≤ IPC31 ≤ MCC10 – MCC09
are both zero
0433 IPC33 is out of range.
When IPC03-B14 = 1, a non-zero IPC33 must be within INC45
≤ IPC33 ≤ INC46
0434 IPC34 is out of range.
If non-zero, IPC34 must be within INC41
≤ IPC34 ≤ INC42
0435 IPC35 is out of range.
if: then:
MCC13 and MCC14 IPC35 must be within 00000 ≤ IPC35 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC35 must be within 00000 ≤ IPC35 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC35 must be within 00000 ≤ IPC35 ≤ MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 IPC35 must be within 00000 ≤ IPC35 ≤ MCC10 – MCC09
are both zero
0437 IPC37 is out of range.
When IPC03-B14 = 1, a non-zero IPC37 must be within INC45
≤ IPC37 ≤ INC46
0438 IPC38 is out of range.
If non-zero, IPC38 must be within INC41
≤ IPC38 ≤ INC42
0439 IPC39 is out of range.
if: then:
MCC13 and MCC14 IPC39 must be within 00000 ≤ IPC39 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC39 must be within 00000 ≤ IPC39 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC39 must be within 00000 ≤ IPC39 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC39 must be within 00000 ≤ IPC39 ≤ MCC10 – MCC09
are both zero
0441 IPC41 is out of range.
When IPC03-B14 = 1, a non-zero IPC41 must be within INC45
≤ IPC41 ≤ INC46
0442 IPC42 is out of range.
If non-zero, IPC42 must be within INC41
≤ IPC42 ≤ INC42
