User Manual

4–20 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 9
0415 IPC15 is out of range.
if: then:
MCC13 and MCC14 IPC15 must be within 00000 ≤ IPC15 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC15 must be within 00000 ≤ IPC15 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC15 must be within 00000 ≤ IPC15 ≤ MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 IPC15 must be within 00000 ≤ IPC15 ≤ MCC10 – MCC09
are both zero
0417 IPC17 is out of range.
When IPC03-B14 = 1, a non-zero IPC17 must be within INC45
≤ IPC17 ≤ INC46
0418 IPC18 is out of range.
If non-zero, IPC18 must be within INC41
≤ IPC18 ≤ INC42
0419 IPC19 is out of range.
if: then:
MCC13 and MCC14 IPC19 must be within 00000 ≤ IPC19 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PC19 must be within 00000 ≤ IPC19 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC19 must be within 00000 ≤ IPC19 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC19 must be within 00000 ≤ IPC19 ≤ MCC10 – MCC09
are both zero
0421 IPC21 is out of range.
When IPC03-B14 = 1, a non-zero IPC21 must be within INC45
≤ IPC21 ≤ INC46
0422 IPC22 is out of range.
If non-zero, IPC22 must be within INC41
≤ IPC22 ≤ INC42
0423 IPC23 is out of range.
if: then:
MCC13 and MCC14 IPC23 must be within 00000 ≤ IPC23 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC23 must be within 00000 ≤ IPC23 ≤ MCC10 – MCC13
MCC14 is zero .
MCC13 is zero and IPC23 must be within 00000 ≤ IPC23 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC23 must be within 00000 ≤ IPC23 ≤ MCC10 – MCC09
are both zero
0425 IPC25 is out of range.
When IPC03-B14 = 1, a non-zero IPC25 must be within INC45
≤ IPC25 ≤ INC46
0426 IPC26 is out of range.
If non-zero, IPC26 must be within INC41
≤ IPC26 ≤ INC42
0427 IPC27 is out of range.
if: then:
MCC13 and MCC14 IPC27 must be within 00000 ≤ IPC27 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC27 must be within 00000 ≤ IPC27 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC27 must be within 00000 ≤ IPC27 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC27 must be within 00000 ≤ IPC27 ≤ MCC10 – MCC09
are both zero
