4–18 Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 8
0216
INC16 is out of range. Valid range is 00000
≤
INC16
≤
09999
0217
INC17 is out of range. Valid range is 00000
≤
INC17
≤
09999
0218
INC18 is out of range. Valid range is 00000
≤
INC18
≤
09999
0219
INC19 is out of range. Valid range is 00000
≤
INC19
≤
09999
0220
INC20 is out of range. Valid range is 00000
≤
INC20
≤
09999
0221
INC21 is out of range. Valid range is 00000
≤
INC21
≤
09999
0222
INC22 is out of range. Valid range is 00000
≤
INC22
≤
09999
0223
INC23 is out of range. Valid range is 00000
≤
INC23
≤
09999
0224
INC24 is out of range. Valid range is 00000
≤
INC24
≤
09999
0225
INC25 is out of range. Valid range is 00000
≤
INC25
≤
09999
0226
INC26 is out of range. Valid range is 00000
≤
INC26
≤
09999
0227
INC27 is out of range. Valid range is 00000
≤
INC27
≤
09999
0228
INC28 is out of range. Valid range is 00000
≤
INC28
≤
09999
0229
INC29 is out of range. Valid range is 00000
≤
INC29
≤
09999
0230
INC30 is out of range. Valid range is 00000
≤
INC30
≤
09999
0231
INC31 is out of range. Valid range is 00000
≤
INC31
≤
09999
0232
INC32 is out of range. Valid range is 00000
≤
INC32
≤
09999
0243
INC43 is out of range. Valid range is 00000
≤
INC43
≤
09999
0244
INC44 is out of range. Valid range is 00000
≤
INC44
≤
09999
0247
INC47 is out of range. Valid range is 00000
≤
INC47
≤
09999
0248
INC48 is out of range. Valid range is 00000
≤
INC48
≤
09999
0249
INC49 is out of range. Valid range is 00000
≤
INC49
≤
09999
0250
INC50 is out of range. Valid range is 00000
≤
INC50
≤
09999
0251
INC51 is out of range. Valid range is 00000
≤
INC51
≤
09999
0252
INC52 is out of range. Valid range is 00000
≤
INC52
≤
09999
0253
INC53 is out of range. Valid range is 00000
≤
INC53
≤
09999
0343 INC43 is equal to INC44. They must not be equal.
0347 INC47 is equal to INC48. They must not be equal.
0442
INC42 is out of range. Valid range is INC41 < INC42
≤
09999
0445
INC45 is out of range. Valid range is 00000
≤
INC45 < INC46
0446
INC46 is out of range. Valid range is INC45 < INC46
≤
09999
0457 INC57 is out of range.
If non-zero, INC57 must be within MCC17 < INC57
≤
MCC18
0458 INC58 is out of range.
If non-zero, INC58 must be within MCC57 < INC58
≤
MCC58
0502 Your bit pattern in INC02-B02, INC02-B01, and INC02-B00
indicates a selected ram (screw) velocity control valve that is unconnected according to
your entries in MCC02 and MCC04.
0506 Your bit pattern in INC02-B06, INC02-B05, and INC02-B04
indicates a selected ram (screw) pressure control valve that is unconnected according to
your entries in MCC02 and MCC04.
ID = 9
IPC – Injection Profile Block
Error Code
Description
ID = 9
0209 IPC09 is out of range.
0209
IPC09
is
out
of
range
.
When IPC03-B01 = 0, IPC09 must be within 00000
≤
IPC09
≤
09999
