1–6 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Pressure Control Limits
EAC41
N45:37 Minimum limit
EAC42 N45:38 Maximum limit
EAC43 N45:39 % output for minimum
EAC44 N45:40 % output for maximum
Velocity Control Limits
EAC45 N45:41 Minimum limit
EAC46 N45:42 Maximum limit
EAC47 N45:43 % output for minimum
EAC48 N45:44 % output for maximum
Advance Stroke Tuning Constants
EAC49 N45:45 Proportional gain, pressure control
EAC50 N45:46 Integral gain, pressure control
EAC51 N45:47 Derivative gain, pressure control
EAC52 N45:48 Proportional gain, velocity control
EAC53 N45:49 Feedforward gain, velocity control
EAC54-56 N45:50-52 RFU
Setpoint for Profile Pressure Alarm
EAC57 N45:53 High pressure alarm
EAC58-64 N45:54-60 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
EPC01 B39:8 Block ID 00000000 00011000
EPC02 B39:9 RFU
EPC03 B39:10 Algorithm and logical bridging selections
EPC04 B39:11 Open/closed loop and ERC selections
Setpoints for Full Advance Profile
EPC05-08 N45:121-124 RFU
EPC09 N45:125 Segment 1 velocity
EPC10 N45:126 Segment 1 pressure
EPC11 N45:127 End of Segment 1 position
EPC12 N45:128 Segment 2 velocity
EPC13 N45:129 Segment 2 pressure
EPC14 N45:130 End of Segment 2 position
EPC15 N45:131 Segment 3 velocity
EPC16 N45:132 Segment 3 pressure
EPC17-20 N45:133-136 RFU
Setpoints for Tip Retract Profile
EPC21 N45:137 Velocity
EPC22 N45:138 Pressure
EPC23 N45:139 End of Tip Retract position
EPC24-26 N45:140-142 RFU
Setpoints for Tip Advance Profile
EPC27 N45:143 Velocity
EPC28 N45:144 Pressure
EPC29 N45:145 End of Tip Advance position
EPC30-32 N45:146-148 RFU
EPC – Ejector
Profile Block
