4–15Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 7
0432 CPC32 is out of range.
if: then:
MCC27 and MCC28 CPC32 must be within 00000
≤
CPC32
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC32 must be within 00000
≤
CPC32
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC32 must be within 00000
≤
CPC32
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC32 must be within 00000
≤
CPC32
≤
MCC24 – MCC23
are both zero
0433 CPC33 is out of range. When CPC03-B14(16) = 1, a non-zero entry for CPC33 must be within
TCC45
≤
CPC33
≤
TCC46
0434
CPC34 is out of range. If non-zero, CPC34 must be within TCC41
≤
CPC34
≤
TCC42
0435 CPC35 is out of range.
if: then:
MCC27 and MCC28 CPC35 must be within 00000
≤
CPC35
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC35 must be within 00000
≤
CPC35
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC35 must be within 00000
≤
CPC35
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC35 must be within 00000
≤
CPC35
≤
MCC24 – MCC23
are both zero
0437
CPC37 is out of range. If non-zero, CPC37 must be within LPC41
≤
CPC37
≤
LPC42
0438 CPC38 is out of range.
if: then:
MCC27 and MCC28 CPC38 must be within 00000
≤
CPC38
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC38 must be within 00000
≤
CPC38
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC38 must be within 00000
≤
CPC38
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC38 must be within 00000
≤
CPC38
≤
MCC24 – MCC23
are both zero
0440
CPC40 is out of range. If non-zero, CPC40 must be within LPC41
≤
CPC40
≤
LPC42
0461 CPC61 is out of range.
if: then:
MCC27 and MCC28 CPC61 must be within CPC62 < CPC61
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC61 must be within CPC62 < CPC61
≤
MCC24 – MCC27
MCC28 is zero .
MCC27 is zero and CPC61 must be within CPC62 < CPC61
≤
MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 CPC61 must be within CPC62 < CPC61
≤
MCC24 – MCC23
are both zero
0462
CPC62 is out of range. CPC62 must be within 00000
≤
CPC62 < CPC61
0463 CPC63 is out of range.
If non-zero, CPC63 must be within MCC31 < CPC63
≤
MCC32
0504 You have selected closed-loop Press/Pos execution for the First Clamp Close Profile by
CPC04-B01 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC
module does not have access to a connected clamp pressure transducer.
