4–14 Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 7
0420 CPC20 is out of range.
if: then:
MCC27 and MCC28 CPC20 must be within 00000
≤
CPC20
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC20 must be within 00000
≤
CPC20
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC20 must be within 00000
≤
CPC20
≤
MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 CPC20 must be within 00000
≤
CPC20
≤
MCC24 – MCC23
are both zero
0421 CPC21 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC21 must be within
SCC45
≤
CPC21
≤
SCC46
0422
CPC22 is out of range. If non-zero, CPC22 must be within SCC41
≤
CPC22
≤
SCC42
0423 CPC23 is out of range.
if: then:
MCC27 and MCC28 CPC23 must be within 00000
≤
CPC23
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC23 must be within 00000
≤
CPC23
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC23 must be within 00000
≤
CPC23
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC23 must be within 00000
≤
CPC23
≤
MCC24 – MCC23
are both zero
0424 CPC24 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC24 must be within
SCC45
≤
CPC24
≤
SCC46
0425
CPC25 is out of range. If non-zero, CPC25 must be within SCC41
≤
CPC25
≤
SCC42
0426 CPC26 is out of range.
if: then:
MCC27 and MCC28 CPC26 must be within 00000
≤
CPC26
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC26 must be within 00000
≤
CPC26
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC26 must be within 00000
≤
CPC26
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC26 must be within 00000
≤
CPC26
≤
MCC24 – MCC23
are both zero
0427 CPC27 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC27 must be within
TCC45
≤
CPC27
≤
TCC46
0428
CPC28 is out of range. If non-zero, CPC28 must be within TCC41
≤
CPC28
≤
TCC42
0429 CPC29 is out of range.
if: then:
MCC27 and MCC28 CPC29 must be within 00000
≤
CPC29
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC29 must be within 00000
≤
CPC29
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC29 must be within 00000
≤
CPC29
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC29 must be within 00000
≤
CPC29
≤
MCC24 – MCC23
are both zero
0430 CPC30 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC30 must be within
TCC45
≤
CPC30
≤
TCC46
0431
CPC31 is out of range. If non-zero, CPC31 must be within TCC41
≤
CPC31
≤
TCC42
