User Manual

4–13Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 7
0230 CPC30 is out of range.
When CPC03-B14 = 0, CPC30 must be within 00000
≤ CPC30 ≤ 09999
0233 CPC33 is out of range.
When CPC03-B14 = 0, CPC33 must be within 00000
≤ CPC33 ≤ 09999
0409 CPC09 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC09 must be within
FCC45
≤ CPC09 ≤ FCC46
0410
CPC10 is out of range. If non-zero, CPC10 must be within FCC41 ≤ CPC10 ≤ FCC42
0411 CPC11 is out of range.
if: then:
MCC27 and MCC28 CPC11 must be within 00000 ≤ CPC11 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC11 must be within 00000 ≤ CPC11 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC11 must be within 00000 ≤ CPC11 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC11 must be within 00000 ≤ CPC11 ≤ MCC24 – MCC23
are both zero
0412 CPC12 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC12 must be within
FCC45
≤ CPC12 ≤ FCC46
0413
CPC13 is out of range. If non-zero, CPC13 must be within FCC41 ≤ CPC13 ≤ FCC42
0414 CPC14 is out of range.
if: then:
MCC27 and MCC28 CPC14 must be within 00000 ≤ CPC14 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC14 must be within 00000 ≤ CPC14 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC14 must be within 00000 ≤ CPC14 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC14 must be within 00000 ≤ CPC14 ≤ MCC24 – MCC23
are both zero
0415 CPC15 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC15 must be within
FCC45
≤ CPC15 ≤ FCC46
0416
CPC16 is out of range. If non-zero, CPC16 must be within FCC41 ≤ CPC16 ≤ FCC42
0417 CPC17 is out of range.
if: then:
MCC27 and MCC28 CPC17 must be within 00000 ≤ CPC17 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and CPC17 must be within 00000 ≤ CPC17 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and CPC17 must be within 00000 ≤ CPC17 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 CPC17 must be within 00000 ≤ CPC17 ≤ MCC24 – MCC23
are both zero
0418 CPC18 is out of range. When CPC03-B14 = 1, a non-zero entry for CPC18 must be within
SCC45
≤ CPC18 ≤ SCC46
0419
CPC19 is out of range. If non-zero, CPC19 must be within SCC41 ≤ CPC19 ≤ SCC42
