4–12 Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 6
0223
LPC23 is out of range. Valid range is 00000
≤
LPC23
≤
09999
0224
LPC24 is out of range. Valid range is 00000
≤
LPC24
≤
09999
0225
LPC25 is out of range. Valid range is 00000
≤
LPC25
≤
09999
0226
LPC26 is out of range. Valid range is 00000
≤
LPC26
≤
09999
0227
LPC27 is out of range. Valid range is 00000
≤
LPC27
≤
09999
0228
LPC28 is out of range. Valid range is 00000
≤
LPC28
≤
09999
0229
LPC29 is out of range. Valid range is 00000
≤
LPC29
≤
09999
0230
LPC30 is out of range. Valid range is 00000
≤
LPC30
≤
09999
0231
LPC31 is out of range. Valid range is 00000
≤
LPC31
≤
09999
0232
LPC32 is out of range. Valid range is 00000
≤
LPC32
≤
09999
0233
LPC33 is out of range. Valid range is 00000
≤
LPC33
≤
09999
0234
LPC34 is out of range. Valid range is 00000
≤
LPC34
≤
09999
0235
LPC35 is out of range. Valid range is 00000
≤
LPC35
≤
09999
0236
LPC36 is out of range. Valid range is 00000
≤
LPC36
≤
09999
0237
LPC37 is out of range. Valid range is 00000
≤
LPC37
≤
09999
0238
LPC38 is out of range. Valid range is 00000
≤
LPC38
≤
09999
0239
LPC39 is out of range. Valid range is 00000
≤
LPC39
≤
09999
0240
LPC40 is out of range. Valid range is 00000
≤
LPC40
≤
09999
0243
LPC43 is out of range. Valid range is 00000
≤
LPC43
≤
09999
0244
LPC44 is out of range. Valid range is 00000
≤
LPC44
≤
09999
0249
LPC49 is out of range. Valid range is 00000
≤
LPC49
≤
09999
0250
LPC50 is out of range. Valid range is 00000
≤
LPC50
≤
09999
0251
LPC51 is out of range. Valid range is 00000
≤
LPC51
≤
09999
0343 LPC43 is equal to LPC44. They must not be equal.
0441
LPC41 is out of range. Valid range is 00000
≤
LPC41 < LPC42
0442
LPC42 is out of range. Valid range is LPC41 < LPC42
≤
09999
0457 LPC57 is out of range.
If non-zero, LPC57 must be within MCC31 < LPC57
≤
MCC32
0506 Your bit pattern in LPC02-B06, LPC02-B05, and LPC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 7
CPC – Clamp Close Profile Block
Error Code
Description
ID = 7
0209 CPC09 is out of range.
When CPC03-B14 = 0, CPC09 must be within 00000
≤
CPC09
≤
09999
0212 CPC12 is out of range.
When CPC03-B14 = 0, CPC12 must be within 00000
≤
CPC12
≤
09999
0215 CPC15 is out of range.
When CPC03-B14 = 0, CPC15 must be within 00000
≤
CPC15
≤
09999
0218 CPC18 is out of range.
When CPC03-B14 = 0, CPC18 must be within 00000
≤
CPC18
≤
09999
0221 CPC21 is out of range.
When CPC03-B14 = 0, CPC21 must be within 00000
≤
CPC21
≤
09999
0224 CPC24 is out of range.
When CPC03-B14 = 0, CPC24 must be within 00000
≤
CPC24
≤
09999
0227 CPC27 is out of range.
When CPC03-B14 = 0, CPC27 must be within 00000
≤
CPC27
≤
09999
