User Manual

4–11Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 5
0236
TCC36 is out of range. Valid range is 00000 ≤ TCC36 ≤ 09999
0237
TCC37 is out of range. Valid range is 00000 ≤ TCC37 ≤ 09999
0238
TCC38 is out of range. Valid range is 00000 ≤ TCC38 ≤ 09999
0239
TCC39 is out of range. Valid range is 00000 ≤ TCC39 ≤ 09999
0240
TCC40 is out of range. Valid range is 00000 ≤ TCC40 ≤ 09999
0243
TCC43 is out of range. Valid range is 00000 ≤ TCC43 ≤ 09999
0244
TCC44 is out of range. Valid range is 00000 ≤ TCC44 ≤ 09999
0247
TCC47 is out of range. Valid range is 00000 ≤ TCC47 ≤ 09999
0248
TCC48 is out of range. Valid range is 00000 ≤ TCC48 ≤ 09999
0249
TCC49 is out of range. Valid range is 00000 ≤ TCC49 ≤ 09999
0250
TCC50 is out of range. Valid range is 00000 ≤ TCC50 ≤ 09999
0251
TCC51 is out of range. Valid range is 00000 ≤ TCC51 ≤ 09999
0252
TCC52 is out of range. Valid range is 00000 ≤ TCC52 ≤ 09999
0253
TCC53 is out of range. Valid range is 00000 ≤ TCC53 ≤ 09999
0343 TCC43 is equal to TCC44. They must not be equal.
0347 TCC47 is equal to TCC48. They must not be equal.
0441
TCC41 is out of range. Valid range is 00000 ≤ TCC41 < TCC42
0442
TCC42 is out of range. Valid range is TCC41 < TCC42 ≤ 09999
0445
TCC45 is out of range. Valid range is 00000 ≤ TCC45 < TCC46
0446
TCC46 is out of range. Valid range is TCC45 < TCC46 ≤ 09999
0457 TCC57 is out of range.
If non-zero, TCC57 must be within MCC31 < TCC57
≤ MCC32
0502 Your bit pattern in TCC02-B02, TCC02-B01, and TCC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02and MCC04.
0506 Your bit pattern in TCC02-B06, TCC02-B05, and TCC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02and MCC04.
ID = 6 LPC – Clamp Low Pressure Close Configuration Block
Error Code
Description ID = 6
0206
LPC06 is out of range. Valid range is 00000 ≤ LPC06 ≤ 09999
0207
LPC07 is out of range. Valid range is 00000 ≤ LPC07 ≤ 09999
0208
LPC08 is out of range. Valid range is 00000 ≤ LPC08 ≤ 09999
0209
LPC09 is out of range. Valid range is 00000 ≤ LPC09 ≤ 09999
0210
LPC10 is out of range. Valid range is 00000 ≤ LPC10 ≤ 09999
0211
LPC11 is out of range. Valid range is 00000 ≤ LPC11 ≤ 09999
0212
LPC12 is out of range. Valid range is 00000 ≤ LPC12 ≤ 09999
0213
LPC13 is out of range. Valid range is 00000 ≤ LPC13 ≤ 09999
0214
LPC14 is out of range. Valid range is 00000 ≤ LPC14 ≤ 09999
0215
LPC15 is out of range. Valid range is 00000 ≤ LPC15 ≤ 09999
0216
LPC16 is out of range. Valid range is 00000 ≤ LPC16 ≤ 09999
0217
LPC17 is out of range. Valid range is 00000 ≤ LPC17 ≤ 09999
0218
LPC18 is out of range. Valid range is 00000 ≤ LPC18 ≤ 09999
0219
LPC19 is out of range. Valid range is 00000 ≤ LPC19 ≤ 09999
0220
LPC20 is out of range. Valid range is 00000 ≤ LPC20 ≤ 09999
0221
LPC21 is out of range. Valid range is 00000 ≤ LPC21 ≤ 09999
0222
LPC22 is out of range. Valid range is 00000 ≤ LPC22 ≤ 09999
