4–10 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 4
0253
SCC53 is out of range. Valid range is 00000 ≤ SCC53 ≤ 09999
0343 SCC43 is equal to SCC44. They must not be equal.
0347 SCC47 is equal to SCC48. These must not be equal.
0441
SCC41 is out of range. Valid range is 00000 ≤ SCC41 < SCC42
0442
SCC42 is out of range. Valid range is SCC41 < SCC42 ≤ 09999
0445
SCC45 is out of range. Valid range is 00000 ≤ SCC45 < SCC46
0446
SCC46 is out of range. Valid range is SCC45 < SCC46 ≤ 09999
0457 SCC57 is out of range.
If non-zero, SCC57 must be within MCC31 < SCC57
≤ MCC32
0502 Your bit pattern in SCC02-B02, SCC02-B01, and SCC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in SCC02-B06, SCC02-B05, and SCC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 5 TCC – Third Clamp Close Configuration Block
Error Code
Description ID = 5
0205
TCC05 is out of range. Valid range is 00000 ≤ TCC05 ≤ 09999
0206
TCC06 is out of range. Valid range is 00000 ≤ TCC06 ≤ 09999
0208
TCC08 is out of range. Valid range is 00000 ≤ TCC08 ≤ 09999
0209
TCC09 is out of range. Valid range is 00000 ≤ TCC09 ≤ 09999
0210
TCC10 is out of range. Valid range is 00000 ≤ TCC10 ≤ 09999
0211
TCC11 is out of range. Valid range is 00000 ≤ TCC11 ≤ 09999
0212
TCC12 is out of range. Valid range is 00000 ≤ TCC12 ≤ 09999
0213
TCC13 is out of range. Valid range is 00000 ≤ TCC13 ≤ 09999
0214
TCC14 is out of range. Valid range is 00000 ≤ TCC14 ≤ 09999
0215
TCC15 is out of range. Valid range is 00000 ≤ TCC15 ≤ 09999
0216
TCC16 is out of range. Valid range is 00000 ≤ TCC16 ≤ 09999
0217
TCC17 is out of range. Valid range is 00000 ≤ TCC17 ≤ 09999
0218
TCC18 is out of range. Valid range is 00000 ≤ TCC18 ≤ 09999
0219
TCC19 is out of range. Valid range is 00000 ≤ TCC19 ≤ 09999
0220
TCC20 is out of range. Valid range is 00000 ≤ TCC20 ≤ 09999
0221
TCC21 is out of range. Valid range is 00000 ≤ TCC21 ≤ 09999
0222
TCC22 is out of range. Valid range is 00000 ≤ TCC22 ≤ 09999
0223
TCC23 is out of range. Valid range is 00000 ≤ TCC23 ≤ 09999
0224
TCC24 is out of range. Valid range is 00000 ≤ TCC24 ≤ 09999
0225
TCC25 is out of range. Valid range is 00000 ≤ TCC25 ≤ 09999
0226
TCC26 is out of range. Valid range is 00000 ≤ TCC26 ≤ 09999
0227
TCC27 is out of range. Valid range is 00000 ≤ TCC27 ≤ 09999
0228
TCC28 is out of range. Valid range is 00000 ≤ TCC28 ≤ 09999
0229
TCC29 is out of range. Valid range is 00000 ≤ TCC29 ≤ 09999
0230
TCC30 is out of range. Valid range is 00000 ≤ TCC30 ≤ 09999
0231
TCC31 is out of range. Valid range is 00000 ≤ TCC31 ≤ 09999
0232
TCC32 is out of range. Valid range is 00000 ≤ TCC32 ≤ 09999
0233
TCC33 is out of range. Valid range is 00000 ≤ TCC33 ≤ 09999
0234
TCC34 is out of range. Valid range is 00000 ≤ TCC34 ≤ 09999
0235
TCC35 is out of range. Valid range is 00000 ≤ TCC35 ≤ 09999
