User Manual

4–8 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 3
0220
FCC20 is out of range. Valid range is 00000 ≤ FCC20 ≤ 09999
0221
FCC21 is out of range. Valid range is 00000 ≤ FCC21 ≤ 09999
0222
FCC22 is out of range. Valid range is 00000 ≤ FCC22 ≤ 09999
0223
FCC23 is out of range. Valid range is 00000 ≤ FCC23 ≤ 09999
0224
FCC24 is out of range. Valid range is 00000 ≤ FCC24 ≤ 09999
0225
FCC25 is out of range. Valid range is 00000 ≤ FCC25 ≤ 09999
0226
FCC26 is out of range. Valid range is 00000 ≤ FCC26 ≤ 09999
0227
FCC27 is out of range. Valid range is 00000 ≤ FCC27 ≤ 09999
0228
FCC28 is out of range. Valid range is 00000 ≤ FCC28 ≤ 09999
0229
FCC29 is out of range. Valid range is 00000 ≤ FCC29 ≤ 09999
0230
FCC30 is out of range. Valid range is 00000 ≤ FCC30 ≤ 09999
0231
FCC31 is out of range. Valid range is 00000 ≤ FCC31 ≤ 09999
0232
FCC32 is out of range. Valid range is 00000 ≤ FCC32 ≤ 09999
0233
FCC33 is out of range. Valid range is 00000 ≤ FCC33 ≤ 09999
0234
FCC34 is out of range. Valid range is 00000 ≤ FCC34 ≤ 09999
0235
FCC35 is out of range. Valid range is 00000 ≤ FCC35 ≤ 09999
0236
FCC36 is out of range. Valid range is 00000 ≤ FCC36 ≤ 09999
0237
FCC37 is out of range. Valid range is 00000 ≤ FCC37 ≤ 09999
0238
FCC38 is out of range. Valid range is 00000 ≤ FCC38 ≤ 09999
0239
FCC39 is out of range. Valid range is 00000 ≤ FCC39 ≤ 09999
0240
FCC40 is out of range. Valid range is 00000 ≤ FCC40 ≤ 09999
0243
FCC43 is out of range. Valid range is 00000 ≤ FCC43 ≤ 09999
0244
FCC44 is out of range. Valid range is 00000 ≤ FCC44 ≤ 09999
0247
FCC47 is out of range. Valid range is 00000 ≤ FCC47 ≤ 09999
0248
FCC48 is out of range. Valid range is 00000 ≤ FCC48 ≤ 09999
0249
FCC49 is out of range. Valid range is 00000 ≤ FCC49 ≤ 09999
0250
FCC50 is out of range. Valid range is 00000 ≤ FCC50 ≤ 09999
0251
FCC51 is out of range. Valid range is 00000 ≤ FCC51 ≤ 09999
0252
FCC52 is out of range. Valid range is 00000 ≤ FCC52 ≤ 09999
0253
FCC53 is out of range. Valid range is 00000 ≤ FCC53 ≤ 09999
0343 FCC43 is equal to FCC44. They must not be equal.
0347 FCC47 is equal to FCC48. They must not be equal.
0441
FCC41 is out of range. Valid range is 00000 ≤ FCC41 < FCC42
0442
FCC42 is out of range. Valid range is FCC41 < FCC42 ≤ 09999
0445
FCC45 is out of range. Valid range is 00000 ≤ FCC45 < FCC46
0446
FCC46 is out of range. Valid range is FCC45 < FCC46 ≤ 09999
0457 FCC57 is out of range.
If non-zero, FCC57 must be within MCC31 < FCC57
≤ MCC32
0502 Your bit pattern in FCC02-B02, FCC02-B01, and FCC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02and MCC04.
0506 Your bit pattern in FCC02-B06, FCC02-B05, and FCC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02and MCC04.
