User Manual

4–6 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description ID = 1
0943 MCC43 is too large.
if: then:
MCC41 and MCC42 MCC43 must be within MCC41 + MCC43 < MCC42 – MCC43
are both non-zero
MCC41 is zero and MCC43 must be within MCC37 + MCC43 < MCC42 – MCC43
MCC42 is non-zero
MCC41 is non-zero MCC43 must be within MCC41 + MCC43 < MCC38 – MCC43
and MCC42 is zero
ID = 2 JGC – Jog Configuration Block
Error Code
Description ID = 2
0209
JGC09 is out of range. Valid range is 00000 ≤ JGC09 ≤ 09999
0210
JGC10 is out of range. Valid range is 00000 ≤ JGC10 ≤ 09999
0211
JGC11 is out of range. Valid range is 00000 ≤ JGC11 ≤ 09999
0212
JGC12 is out of range. Valid range is 00000 ≤ JGC12 ≤ 09999
0213
JGC13 is out of range. Valid range is 00000 ≤ JGC13 ≤ 09999
0214
JGC14 is out of range. Valid range is 00000 ≤ JGC14 ≤ 09999
0215
JGC15 is out of range. Valid range is 00000 ≤ JGC15 ≤ 09999
0216
JGC16 is out of range. Valid range is 00000 ≤ JGC16 ≤ 09999
0217
JGC17 is out of range. Valid range is 00000 ≤ JGC17 ≤ 09999
0218
JGC18 is out of range. Valid range is 00000 ≤ JGC18 ≤ 09999
0219
JGC19 is out of range. Valid range is 00000 ≤ JGC19 ≤ 09999
0220
JGC20 is out of range. Valid range is 00000 ≤ JGC20 ≤ 09999
0221
JGC21 is out of range. Valid range is 00000 ≤ JGC21 ≤ 09999
0222
JGC22 is out of range. Valid range is 00000 ≤ JGC22 ≤ 09999
0223
JGC23 is out of range. Valid range is 00000 ≤ JGC23 ≤ 09999
0224
JGC24 is out of range. Valid range is 00000 ≤ JGC24 ≤ 09999
0225
JGC25 is out of range. Valid range is 00000 ≤ JGC25 ≤ 09999
0226
JGC26 is out of range. Valid range is 00000 ≤ JGC26 ≤ 09999
0227
JGC27 is out of range. Valid range is 00000 ≤ JGC27 ≤ 09999
0228
JGC28 is out of range. Valid range is 00000 ≤ JGC28 ≤ 09999
0229
JGC29 is out of range. Valid range is 00000 ≤ JGC29 ≤ 09999
0230
JGC30 is out of range. Valid range is 00000 ≤ JGC30 ≤ 09999
0231
JGC31 is out of range. Valid range is 00000 ≤ JGC31 ≤ 09999
0232
JGC32 is out of range. Valid range is 00000 ≤ JGC32 ≤ 09999
0233
JGC33 is out of range. Valid range is 00000 ≤ JGC33 ≤ 09999
0234
JGC34 is out of range. Valid range is 00000 ≤ JGC34 ≤ 09999
0235
JGC35 is out of range. Valid range is 00000 ≤ JGC35 ≤ 09999
0236
JGC36 is out of range. Valid range is 00000 ≤ JGC36 ≤ 09999
0237
JGC37 is out of range. Valid range is 00000 ≤ JGC37 ≤ 09999
0238
JGC38 is out of range. Valid range is 00000 ≤ JGC38 ≤ 09999
0239
JGC39 is out of range. Valid range is 00000 ≤ JGC39 ≤ 09999
0240
JGC40 is out of range. Valid range is 00000 ≤ JGC40 ≤ 09999
0241
JGC41 is out of range. Valid range is 00000 ≤ JGC41 ≤ 09999
0242
JGC42 is out of range. Valid range is 00000 ≤ JGC42 ≤ 09999
0243
JGC43 is out of range. Valid range is 00000 ≤ JGC43 ≤ 09999
