User Manual

1–5Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
EAC01 B39:0 Block ID 00000000 00010110
EAC02 B39:1 Selected valve configurations
EAC03-04 B39:2-3 RFU
Expert Response Compensation Percentage
EAC05 N45:1 ERC % minimum velocity
EAC06 N45:2 ERC % minimum pressure
EAC07 N45:3 RFU
Watchdog Timer
EAC08 N45:4 Profile timer preset
Set-output Values for Unselected Valves (During Advance)
EAC09 N45:5 Output #1
EAC10 N45:6 Output #2
EAC11 N45:7 Output #3
EAC12 N45:8 Output #4
EAC13 N45:9 Output #5
EAC14 N45:10 Output #6
EAC15 N45:11 Output #7
EAC16 N45:12 Output #8
Acceleration Ramp Rates
EAC17 N45:13 Output #1
EAC18 N45:14 Output #2
EAC19 N45:15 Output #3
EAC20 N45:16 Output #4
EAC21 N45:17 Output #5
EAC22 N45:18 Output #6
EAC23 N45:19 Output #7
EAC24 N45:20 Output #8
Deceleration Ramp Rates
EAC25 N45:21 Output #1
EAC26 N45:22 Output #2
EAC27 N45:23 Output #3
EAC28 N45:24 Output #4
EAC29 N45:25 Output #5
EAC30 N45:26 Output #6
EAC31 N45:27 Output #7
EAC32 N45:28 Output #8
End of Stroke Set-output Values
EAC33 N45:29 Output #1
EAC34 N45:30 Output #2
EAC35 N45:31 Output #3
EAC36 N45:32 Output #4
EAC37 N45:33 Output #5
EAC38 N45:34 Output #6
EAC39 N45:35 Output #7
EAC40 N45:36 Output #8
EAC – Ejector Advance
Configuration Block
