User Manual

4–4 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description ID = 1
0248 MCC48 is out of range. MCC48 must be within:
00000
≤ MCC48 ≤ 01000 (0 to 10 V dc sensor)
00100 ≤ MCC48 ≤ 00500 (1 to 5 V dc sensor)
00400 ≤ MCC48 ≤ 02000 (4 to 20 mA dc sensor)
0250
MCC50 is out of range. Valid range is 00000 ≤ MCC50 ≤ 00099
0253 MCC53 is out of range. MCC53 must be within:
00000
≤ MCC53 ≤ 01000 (0 to 10 V dc sensor)
00100 ≤ MCC53 ≤ 00500 (1 to 5 V dc sensor)
00400
≤ MCC53 ≤ 02000 (4 to 20 mA dc sensor)
0254 MCC54 is out of range. MCC54 must be within:
00000
≤ MCC54 ≤ 01000 (0 to 10 V dc sensor)
00100 ≤ MCC54 ≤ 00500 (1 to 5 V dc sensor)
00400
≤ MCC54 ≤ 02000 (4 to 20 mA dc sensor)
0256
MCC56 is out of range. Valid range is 00000 ≤ MCC56 ≤ 00099
0259 MCC59 is out of range. MCC59 must be within:
00000
≤ MCC59 ≤ 01000 (0 to 10 V dc sensor)
00100 ≤ MCC59 ≤ 00500 (1 to 5 V dc sensor)
00400
≤ MCC59 ≤ 02000 (4 to 20 mA dc sensor)
0260 MCC60 is out of range. MCC60 must be within
00000
≤ MCC60 ≤ 01000 (0 to 10 V dc sensor)
00100
≤ MCC60 ≤ 00500 (1 to 5 V dc sensor)
00400 ≤ MCC60 ≤ 02000 (4 to 20 mA dc sensor)
0262
MCC62 is out of range. Valid range is 00000 ≤ MCC62 ≤ 00099
0311 MCC11 is equal to MCC12. They must not be equal.
0319 MCC19 is equal to MCC20. They must not be equal.
0325 MCC25 is equal to MCC26. They must not be equal.
0333 MCC33 is equal to MCC34. They must not be equal.
0339 MCC39 is equal to MCC40. They must not be equal.
0347 MCC47 is equal to MCC48. They must not be equal.
0353 MCC53 is equal to MCC54. They must not be equal.
0359 MCC59 is equal to MCC60. They must not be equal.
0405-0408
Your entry for MCC05-MCC08 is out of range. Valid range is –1000 ≤ entry ≤ +1000.
0409
MCC09 is out of range. Valid range is 00000 ≤ MCC09 < MCC10
0410
MCC10 is out of range. Valid range is MCC09 < MCC10 ≤ 09999
0413 Your non-zero entry for MCC13 is out of range. If MCC14 is non-zero, MCC13 must be
within MCC09
≤ MCC13 < MCC14
If MCC14 is zero, MCC13 must be within MCC09 ≤ MCC13 < MCC10
0414 Your non-zero entry for MCC14 is out of range. If MCC13 is non-zero, MCC14 must be
within MCC13 < MCC14
≤ MCC10
If MCC13 is zero, MCC14 must be within MCC09 < MCC14 ≤ MCC10
0417
MCC17 is out of range. Valid range is 00000 ≤ MCC17 < MCC18
0418
MCC18 is out of range. Valid range is MCC17 < MCC18 ≤ 09999
0421 MCC21 is out of range.
If non-zero, MCC21 must be within MCC17 < MCC21
≤ MCC18
0423
MCC23 is out of range. Valid range is 00000 ≤ MCC23 < MCC24
0424
MCC24 is out of range. Valid range is MCC23 < MCC24 ≤ 09999
0427 Your non-zero entry for MCC27 is out of range.
If MCC28 is non-zero, MCC27 must be within MCC23
≤ MCC27 < MCC28
If MCC28 is zero, MCC27 must be within MCC23
≤ MCC27 < MCC24
0428 Your non-zero entry for MCC28 is out of range.
If MCC27 is non-zero, MCC28 must be within MCC27 < MCC28
≤ MCC24
If MCC27 is zero, MCC28 must be within MCC23 < MCC28 ≤ MCC24
0431
MCC31 is out of range. Valid range is 00000 ≤ MCC31 < MCC32
