4–3Programming Error Codes
Publication
1771-6.5.88 – July 1997
ID = 1
MCC – Module Configuration Command Block
Error Code
Description
ID = 1
0211 MCC11 is out of range. MCC11 must be within:
00000
≤
MCC11
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC11
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC11
≤
02000 (4 to 20 mA dc sensor)
0212 MCC12 is out of range. MCC12 must be within:
00000
≤
MCC12
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC12
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC12
≤
02000 (4 to 20 mA dc sensor)
0215
MCC15 is out of range. Valid range is 00000
≤
MCC15
≤
00099
0216
MCC16 is out of range. Valid range is 00000
≤
MCC16
≤
00099
0219 MCC19 is out of range. MCC19 must be within:
00000
≤
MCC19
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC19
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC19
≤
02000 (4 to 20 mA dc sensor)
0220 MCC20 is out of range. MCC20 must be within:
00000
≤
MCC20
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC20
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC20
≤
02000 (4 to 20 mA dc sensor)
0222
MCC22 is out of range. Valid range is 00000
≤
MCC22
≤
00099
0225 MCC25 is out of range. MCC25 must be within:
00000
≤
MCC25
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC25
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC25
≤
02000 (4 to 20 mA dc sensor)
0226 MCC26 is out of range. MCC26 must be within:
00000
≤
MCC26
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC26
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC26
≤
02000 (4 to 20 mA dc sensor)
0229
MCC29 is out of range. Valid range is 00000
≤
MCC29
≤
00099
0230
MCC30 is out of range. Valid range is 00000
≤
MCC30
≤
00099
0233 MCC33 is out of range. MCC33 must be within:
00000
≤
MCC33
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC33
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC33
≤
02000 (4 to 20 mA dc sensor)
0234 MCC34 is out of range. MCC34 must be within:
00000
≤
MCC34
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC34
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC34
≤
02000 (4 to 20 mA dc sensor)
0236
MCC36 is out of range. Valid range is 00000
≤
MCC36
≤
00099
0239 MCC39 is out of range. MCC39 must be within:
00000
≤
MCC39
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC39
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC39
≤
02000 (4 to 20 mA dc sensor)
0240 MCC40 is out of range. MCC40 must be within:
00000
≤
MCC40
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC40
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC40
≤
02000 (4 to 20 mA dc sensor)
0243
MCC43 is out of range. Valid range is 00000
≤
MCC43
≤
00099
0244
MCC44 is out of range. Valid range is 00000
≤
MCC44
≤
00099
0247 MCC47 is out of range. MCC47 must be within:
00000
≤
MCC47
≤
01000 (0 to 10 V dc sensor)
00100
≤
MCC47
≤
00500 (1 to 5 V dc sensor)
00400
≤
MCC47
≤
02000 (4 to 20 mA dc sensor)
