User Manual

3–45Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SYS
Word Bit Description
SYS22 Status of End of Profile Set-Output Execution
B00 = 0 Normal
= 1 End of First Clamp Close Profile Set-Output in Progress
The module sets this bit when holding its outputs to FCC33 - FCC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B01 = 0 Normal
= 1 End of Second Clamp Close Profile Set-Output in Progress
The module sets this bit when holding its outputs to SCC33 - 40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B02 = 0 Normal
= 1 End of Third Clamp Close Profile Set-Output in Progress
The module sets this bit when holding its outputs to TCC33 - TCC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B03 = 0 Normal
= 1 End of Clamp LP Close Profile Set-Output in Progress
The module sets this bit when holding its outputs to LPC33 - LPC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B04 = 0 Normal
= 1 Open
B05 = 0 Normal
= 1 Open
B06 = 0 Normal
= 1 End of Hold Profile Set-Output in Progress
The module sets this bit when holding its outputs to HDC33 - HDC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B07 = 0 Normal
= 1 End of Pre-decompression Movement Set-Output in Progress
The module sets this bit when holding its outputs to PRC33 - PRC40 after completion of the movement.
The module resets this bit when it receives any new action execution command bit.
B08 = 0 Normal
= 1 End of Plastication Profile Set-Output in Progress
The module sets this bit when holding its outputs to PLC33 - PLC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B09 = 0 Normal
= 1 End of Post-decompression Movement Set-Output in Progress
The module sets this bit when holding its outputs in PSC33 - PSC40 after completion of the movement.
The module resets this bit when it receives any new action execution command bit.
B10 = 0 Normal
= 1 End of First Clamp Open Profile Set-Output in Progress
The module sets this bit when holding its outputs to FOC33 - FOC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B11 = 0 Normal
= 1 End of Second Clamp Open Profile Set-Output in Progress
The module sets this bit when holding its outputs to SOC33 - SOC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B12 = 0 Normal
= 1 End of Third Clamp Open Profile Set-Output in Progress
The module sets this bit when holding its outputs to TOC33 - TOC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B13 = 0 Normal
= 1 End of Clamp Open Slow Profile Set-Output in Progress
The module sets this bit when holding its outputs to OSC33 - OSC40 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B14 = 0 Normal
= 1 End of Ejector Advance Set-Output in Progress
The module sets this bit when holding its outputs to EAC33 - EAC40 after completion of an ejector advance stroke.
The module resets this bit when it receives any new action execution command bit, or when commanded to continue
the ejector profile by DYC03-B15 = 1.
