User Manual

3–43Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SYS
Word Bit Description
SYS21 Status of Profile Execution
B00 = 0 Normal
= 1 First Clamp Close Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
Module does not leave this bit set when holding outputs to FCC33 - 40 at completion of the First Clamp Close profile.
B01 = 0 Normal
= 1 Second Clamp Close Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
Module does not leave this bit set when holding outputs to SCC33 - 40 at completion of Second Clamp Close profile.
B02 = 0 Normal
= 1 Third Clamp Close Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
Module does not leave this bit set when holding outputs to TCC33 - 40 at completion of the Third Clamp Close profile.
B03 = 0 Normal
= 1 Low Pressure Close (LPC) Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
Mdule does not leave this bit set when holding outputs to LPC33 - 40 at completion of Clamp LPC profile.
B04 = 0 Normal
= 1 Injection Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
B05 = 0 Normal
= 1 Pack Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
B06 = 0 Normal
= 1 Hold Profile in Progress
The module sets this bit when it starts the profile.
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding outputs to HDC33 - 40 at completion of the hold profile.
B07 = 0 Normal
= 1 Pre-decompression Movement in Progress
The module sets this bit when it starts the movement.
The module resets this bit when:
S it completes the movement, or
S it receives a new action execution command that terminates the movement
Module does not leave this bit set when holding outputs to PRC33 - 40 at completion of Pre-decompression movement.
