3–42 Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
SYS19 Programming-error Alarms
The module latches bits when it attempts to decode a newly received copy of the subject command block and is forced
to discard the data due to the presence of a programming error in the newly received block. The module does not latch
any bit associated with an unrecognizable command block. The module unlatches each bit when it successfully de-
codes the referenced command block and places the new data into operational memory.
When this bit
is latched ON:
the module detected a programming error in:
B00 MCC The module ceases all action execution and sets its outputs to zero when forced to set this bit. The module
does not respond to any action execution commands as long as this bit remains SET.
B01 JGC
B02 FCC
B03 SCC
B04 TCC
B05 LPC
B06 CPC
B07 INC
B08 IPC
B09 PKC
B10 HDC
B11 HPC
B12 PRC
B13 PLC
B14 PPC
B15 PSC
SYS20 Programming-error Alarms
The module latches bits when it attempts to decode a newly received copy of the subject command block and is forced
to discard the data due to the presence of a programming error in the newly received block. The module does not latch
any bit associated with an unrecognizable command block. The module unlatches each bit when it successfully de-
codes the referenced command block and places the new data into operational memory.
When this bit
is latched ON:
the module detected a programming error in:
B00 FOC
B01 SOC
B02 TOC
B03 OSC
B04 OPC
When this bit
is latched ON:
the module detected a programming error in:
B05 EAC
B06 ERC
B07 EPC
B08 DYC The module ceases all action execution and sets its outputs to zero when forced to set this bit. The module
does not respond to any action execution commands as long as this bit remains SET.
B09 RLC
B10 CLC
B11 PTC
B12-B15 Open
