User Manual

3–39Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SYS
Word Bit Description
B04 = 0 Normal
= 1 Pack/Hold Command Block Rejected
The module latches this bit when it receives a PKC, HDC, HPC, or PRC for decode and any one of SYS21-B05 -
SYS21-B07 is SET.
The module unlatches this bit when it receives a PKC, HDC, HPC, or PRC for decode and all of SYS21-B05 -
SYS21-B07 are RESET.
B05 = 0 Normal
= 1 Plastication Command Block Rejected
The module latches this bit when it receives a PLC, PPC, or PSC for decode and SYS21-B08 or SYS21-B09 is SET.
The module unlatches this bit when it receives a PLC, PPC, or PSC for decode and both SYS21-B08 and SYS21-B09
are RESET.
B06 = 0 Normal
= 1 Clamp Open Command Block Rejected
The module latches this bit when it receives an FOC, SOC, TOC, OSC, or OPC for decode and any one of SYS21-B10
- SYS21-B13 is SET.
The module unlatches this bit when it receives an FOC, SOC, TOC, OSC, or OPC for decode and all of SYS21-B10 -
SYS21-B13 are RESET.
B07 = 0 Normal
= 1 Ejector Command Block Rejected
The module latches this bit when it receives an EAC, ERC, or EPC for decode and SYS21-B14 is SET.
The module unlatches this bit when it receives an EAC, ERC, or EPC for decode and SYS21-B14 is RESET.
B08 = 0 Normal
= 1 Ejector Not Back
The module latches this bit and ignores the action execution command if ejector position exceeds EPC63 when the
module decodes a valid Dynamic Command block having one of the following four action execution command bits SET.
DYC02-B00 - Execute First Close Profile
DYC02-B01 - Execute Second Close Profile
DYC02-B02 - Execute Third Close Profile
DYC02-B03 - Execute LP Close Profile
The module latches this bit and sets its outputs to zero if it is executing one of the four clamp close profiles and the
ejector achieves a position greater than EPC63.
The module unlatches this bit when ejector position equals or is less than EPC63, or when the module decodes a valid
DYC having all four action execution command bits RESET.
B09 = 0 Normal
= 1 Ejector Action Prohibited
The module latches this bit and ignores the action execution command if EPC03-B09 is RESET and clamp position
equals or is less than EPC62 when the module decodes a valid DYC having DYC02-B14 or DYC03-B15 is SET.
The module latches this bit and sets its outputs to zero if clamp position equals or is less than EPC62 during the Ejector
Profile.
The module unlatches this bit when clamp position exceeds EPC62, or when the module decodes a valid DYC having
DYC02-B14 and DYC03-B15 RESET.
B09 = 0 Normal
= 1 Ejector Action Prohibited
The module latches this bit and ignores the action execution command if EPC03-B09 is RESET and clamp position
equals or is less than EPC62 when the module decodes a valid DYC having DYC02-B14 or DYC03-B15 is SET.
The module latches this bit and sets its outputs to zero if clamp position equals or is less than EPC62 during the Ejector
Profile.
The module unlatches this bit when clamp position exceeds EPC62, or when the module decodes a valid DYC having
DYC02-B14 and DYC03-B15 RESET.
B10 The module latches this bit when it receives a PTC block for decode, and SYS53-B00 is SET.
The module unlatches this bit when it receives a PTC block for decode, and SYS53-B00 is RESET.
Process trace command rejected.
B11-B15 Open
