3–38 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
SYS13 B12 = 0 Normal
= 1 Second Clamp Open Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B11 is SET
S SYS16-B04 is RESET
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B11.
B13 = 0 Normal
= 1 Third Clamp Open Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B12 is SET
S SYS16-B04 is RESET
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B12.
B14 = 0 Normal
= 1 Clamp Open Slow Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B13 is SET
S SYS16-B04 is RESET
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B13.
B15 = 0 Normal
= 1 Ejector Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B14 is SET.
S SYS16-B07 is RESET.
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B14.
SYS14 Miscellaneous
B00 = 0 Normal
= 1 Dual-command Error
The module latches this bit when it decodes a valid Dynamic Command Block having more than one of the twenty-four
action execution command bits SET. Bits DYC01-B08 through DYC01-B15 and all 16 bits in DYC02 are the 24 action
execution commands available to the end user for control of the module.
The module unlatches this bit when it decodes a valid Dynamic Command Block having one or none of the action ex-
ecution bits SET.
B01 Open
Command Block Rejection Errors
The module discards and does not attempt to decode any command block associated with a profiled movement in
The module discards and does not attempt to decode any command block associated with a profiled movement in
progress.
B02 = 0 Normal
= 1 Clamp Close Command Block Rejected
The module latches this bit when it receives an FCC, SCC, TCC, LPC, or CPC for decode and any one of SYS21-B00 -
SYS21-B03 is SET.
The module unlatches this bit when it receives an FCC, SCC, TCC, LPC, or CPC for decode and all of SYS21-B00 -
SYS21-B03 are RESET.
B03 = 0 Normal
= 1 Injection Command Block Rejected
The module latches this bit when it receives an INC or IPC for decode and SYS21-B04 is SET.
The module unlatches this bit when it receives an INC or IPC for decode and SYS21-B04 is RESET.
