3–35Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
SYS
Word Bit Description
B02 Clamp Overtravel on Close
B03 Clamp Overtravel on Open
When this bit
is latched ON:
the module detected this alarm:
B04 Ejector Overtravel on Retract
B05 Ejector Overtravel on Advance
B06 Clamp Close Profile Overtravel into Mold Protection Zone
B07 Clamp Open Profile Overtravel into Open Slow Zone
B08-B15 Reserved for the module. Do not use.
SYS12 Alarm Status for Loss of Input Sensor (Latched)
The module latches alarm bits on each false-to-true transition of the corresponding real-time alarm bit in SYS08. The
module unlatches all 16 bits when it receives a false-to-true transition of DYC03-B09.
When this bit
is latched ON,
the module detected this alarm
B00 Loss of Ram (Screw) Position Sensor (except when MCC64 is SET)
B01 Loss of Ram (Screw) Pressure Sensor (except when MCC64 is SET)
B02 Loss of Clamp Position Sensor (except when MCC64 is SET)
B03 Loss of Clamp Pressure Sensor (except when MCC64 is SET)
B04 Loss of Ejector Position Sensor (except when MCC64 is SET)
B05 Loss of Ejector Pressure Sensor (except when MCC64 is SET)
B06 Loss of Screw RPM Sensor (except when MCC64 is SET)
B07 Loss of Cavity Pressure Sensor (except when MCC64 is SET)
B08-B15 Open
SYS13 Action-execution Command Errors
B00
= 0 Normal
= 1 Jog Command Error
The module latches this bit when SYS15-B01 is RESET and one of the following is true:
S
DYC01-B09 is SET
S
DYC01-B10 is SET
S
DYC01-B11 is SET
DYC01 B12 i SET
C0 S
S
DYC01-B12 is SET
S
DYC01-B13 is SET
S
DYC01-B14 is SET
S
DYC01-B15 is SET
The module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than the ones
listed above.
B01 = 0 Normal
= 1 First Clamp Close Profile Command Error
The module latches this bit when all of the following are true:
S
DYC02-B00 is SET
S
CPC03-B08 is SET
S
SYS15-B02 is RESET
The module also latches this bit when both of the following are true:
S
DYC02-B00 is SET
S
SYS15-B06 is RESET
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B00.
