User Manual

3–34 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word
Bit Description
SYS09 High Pressure Alarm Status (Latched)
The module latches alarm bits on each false-to-true transition of the corresponding real-time alarm bit in SYS05. The
module unlatches all 16 bits when it receives a false- to-true transition of DYC03-B09. You can inhibit each bit by set-
ting its associated alarm setpoint to zero.
When this bit
is latched ON:
the module detected this alarm:
B00 High Ram (Screw) Pressure
B01 High Clamp Pressure
B02 High Ejector Pressure
When this bit
is latched ON:
the module detected this alarm:
B03 High Screw RPM
B04 High Cavity (or System) Pressure
B05-B07 Open
B08 High Screw Rotate Jog RPM
B09 High Ram (Screw) Jog Pressure
B10 High Clamp Jog Pressure
B11 High Ejector Jog Pressure
B12 First Clamp Close Profile High Clamp Pressure
B13 Second Clamp Close Profile High Clamp Pressure
B14 Third Clamp Close Profile High Clamp Pressure
B15 Clamp Low Press Close Profile High Clamp Pressure
SYS10 High Pressure Alarm Status (Latched)
The module latches alarm bits on each false-to-true transition of the corresponding real-time alarm bit in SYS06. The
module unlatches all 16 bits when it receives a false-to-true transition of DYC03-B09. You can inhibit each bit by setting
its associated alarm setpoint to zero.
When this bit
is latched ON:
the module detected this alarm:
B00 Injection Profile High Ram (Screw) Pressure
B01 Injection Profile High Cavity Pressure
B02 Pack Profile High Ram (Screw) Pressure
B03 Pack Profile High Cavity Pressure
B04 Hold Profile High Ram (Screw) Pressure
B05 Hold Profile High Cavity Pressure
B06 Pre-decompress Movement High Ram (Screw) Pressure
B07 Plastication Profile High Ram (Screw) Pressure
B08 Post-decompress Movement High Ram (Screw) Pressure
B09 First Clamp Open Profile High Clamp Pressure
B10 Second Clamp Open Profile High Clamp Pressure
B11 Third Clamp Open Profile High Clamp Pressure
B12 Clamp Open Slow Profile High Clamp Pressure
B13 Ejector Profile High Ejector Pressure
B14-B15 Open
SYS11 Overtravel Alarm Status (Latched)
The module latches alarm bits on each false-to-true transition of the corresponding real-time alarm bit in SYS07. The
module unlatches all 16 bits when it receives a false-to-true transition of DYC03-B09. You can inhibit each bit by setting
its associated alarm setpoint to zero.
When this bit
is latched ON:
the module detected this alarm:
B00 Ram (Screw) Overtravel at Bottom
B01 Ram (Screw) Overtravel at Top
