1–3Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
CPC01 B37:16 Block ID 00000000 00000111
CPC02 B37:17 RFU
CPC03 B37:18 Algorithm and logical bridging selections
CPC04 B37:19 Open/closed loop and ERC selections
Setpoints for 1st Clamp Close Profile
CPC05-08 N43:241-244 RFU
CPC09 N43:245 Segment 1 velocity
CPC10 N43:246 Segment 1 pressure
CPC11 N43:247 End of Segment 1 position
CPC12 N43:248 Segment 2 velocity
CPC13 N43:249 Segment 2 pressure
CPC14 N43:250 End of Segment 2 position
CPC15 N43:251 Segment 3 velocity
CPC16 N43:252 Segment 3 pressure
CPC17 N43:253 End of Segment 3 position
Setpoints for 2nd Clamp Close Profile
CPC18 N43:254 Segment 4 velocity
CPC19 N43:255 Segment 4 pressure
CPC20 N43:256 End of Segment 4 position
CPC21 N43:257 Segment 5 velocity
CPC22 N43:258 Segment 5 pressure
CPC23 N43:259 End of Segment 5 position
CPC24 N43:260 Segment 6 velocity
CPC25 N43:261 Segment 6 pressure
CPC26 N43:262 End of Segment 6 position
Setpoints for 3rd Clamp Close Profile
CPC27 N43:263 Segment 7 velocity
CPC28 N43:264 Segment 7 pressure
CPC29 N43:265 End of Segment 7 position
CPC30 N43:266 Segment 8 velocity
CPC31 N43:267 Segment 8 pressure
CPC32 N43:268 End of Segment 8 position
CPC33 N43:269 Segment 9 velocity
CPC34 N43:270 Segment 9 pressure
CPC35 N43:271 End of Segment 9 position
Setpoints for Clamp Low Pressure Close Profile
CPC36 N43:272 RFU
CPC37 N43:273 Segment 1 pressure
CPC38 N43:274 End of Segment 1 position
CPC39 N43:275 RFU
CPC40 N43:276 Segment 2 pressure
CPC41-60 N43:277-296 RFU
Critical Process Setpoints
CPC61 N43:297 Start position for clamp LPC
CPC62 N43:298 Mold safe (parting line) position
CPC63 N43:299 Full tonnage pressure
CPC64 N43:300 RFU
CPC – Clamp Close
Profile Block
