User Manual

3–29Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SYS
Word Bit Description
SYS04 Watchdog Time-Out Status
B00 = 0 Normal
= 1 First Clamp Close Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (FCC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding its outputs to FCC33 - FCC40 at completion of this profile.
B01 = 0 Normal
= 1 Second Clamp Close Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (SCC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding its outputs to SCC33 - SCC40 at completion of this profile.
B02 = 0 Normal
= 1 Third Clamp Close Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (TCC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding its outputs to TCC33 - TCC40 at completion of this profile.
B03 = 0 Normal
= 1 Clamp Low Pressure Close Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (LPC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding its outputs to LPC33 - LPC40 at completion of this profile.
B04-B06 Open
B07 = 0 Normal
= 1 Pre-decompression Movement Watchdog Time-Out
Module sets this bit when the time required for the movement equals or exceeds the Watchdog Timer preset (PRC08).
The module resets this bit when:
S it completes the movement, or
S it receives a new action execution command that terminates the movement
The module does not leave this bit set when holding its outputs to PRC33 - PRC40 at completion of this movement.
B08 = 0 Normal
= 1 Plastication Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (PLC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile
The module does not leave this bit set when holding its outputs to PLC33 - PLC40 at completion of this profile.
B09 = 0 Normal
= 1 Post-decompression Movement Watchdog Time-Out
The module sets this bit when the time required for the movement equals or exceeds the Watchdog Timer preset
(PSC08). The module resets this bit when:
S it completes the movement, or
S it receives a new action execution command that terminates the movement
The module does not leave this bit set when holding its outputs to PSC33 - PSC40 at completion of this movement.
B10 = 0 Normal
= 1 First Clamp Open Profile Watchdog Time-Out
The module sets this bit when the time required for the profile equals or exceeds the Watchdog Timer preset (FOC08).
The module resets this bit when:
S it completes the profile, or
S it receives a new action execution command that terminates the profile.
The module does not leave this bit set when holding its outputs to FOC33 - FOC40 at completion of this profile.
