User Manual

3–28 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word
Bit Description
SYS03 B09 = 0 Normal
= 1 Open Dwell Timer Timing
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a clamp position transducer, the module
sets this bit when the internal Mold Open Dwell Timer is timing and the accumulated Mold Open Dwell Time (SYS59) is
less than Mold Open Dwell Timer preset (OPC63).
B10 = 0 Normal
= 1 Ejector Forward Dwell Timer Timing
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ejector position transducer, the module
sets this bit when the internal Ejector Forward Dwell Timer is timing and its accumulated time is less than its preset
(EPC57).
B11 = 0 Normal
= 1 Cycle Complete
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a clamp position transducer but
not an
ejector position transducer, the module:
S latches this bit on each F-toT transition of SYS02-B13 if OPC63 is zero
S latches this bit on each T-to-F transition of SYS03-B09
S unlatches this bit upon receipt of any new action execution command
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a clamp position transducer and also an
ejector position transducer, the module performs as follows:
if and then the module:
OPC63 is zero EPC03-B09 is SET latches this bit on each F-to-T transition of SYS02-B13
OPC63 is zero an action execution command
has not been received since
the last F-to-T transition of
SYS02-B14
latches this bit on each F-to-T transition of SYS02-B13
OPC63 is zero SYS03-B07 is SET latches this bit on each F-to-T transition of SYS02-B14
OPC03-B15 is RESET,
SYS03-B07 is SET
SYS03-B09 is RESET latches this bit on each F-to-T transition of SYS02-B14
an action execution
command has not been
received since the last
F-to-T transition of
SYS02-B14
N/A latches this bit on each T-to-F transition of SYS03-B09
it receives any new action
execution command
N/A unlatches this bit
B12 = 0 Normal
= 1 Ejector Fully Advanced
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ejector position transducer, the module
sets this bit when ejector position equals or exceeds the Ejector Fully Advanced position (EPC59).
B13 = 0 Normal
= 1 Ejector Beyond Tip Advance Position
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ejector position transducer, the module:
S sets this bit when ejector position equals or exceeds a non-zero Ejector End of Tip Advance position (EPC29) or,
S sets this bit when ejector position equals or exceeds the Ejector Fully Advanced position (EPC59) and EPC29 is zero
B14 = 0 Normal
= 1 Ejector Inside Tip Retract Position
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ejector position transducer, the module:
S sets this bit when ejector position equals or is less than a non-zero Ejector End of Tip Retract position (EPC23)
S sets this bit when ejector position equals or is less than Ejector Fully Retracted position (EPC60) and EPC23 is zero
B15 = 0 Normal
= 1 Ejector Fully Retracted
If bit patterns in MCC02 and MCC03 indicate the module is connected to an ejector position transducer, the module
sets this bit when ejector position equals or is less than Ejector Fully Retracted position (EPC60) with hysteresis of
0.05” (0.5mm).
