3–26 Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
SYS02 Profile Execution Status
The module sets each bit, SYS02 - B00 through B14 when:
S
it completes the profile or movement, or
S
it receives a new action execution command that terminates the profile or movement
The module resets each bit, SYS02 - B00 through B14 when:
S
it starts the profile or movement, or
S
it receives a valid DYC with DYC03-B10 SET
B00 = 0 Normal
= 1 First Clamp Close Profile Complete
B01 = 0 Normal
= 1 Second Clamp Close Profile Complete
B02 = 0 Normal
= 1 Third Clamp Close Profile Complete
B03 = 0 Normal
= 1 Clamp Low Pressure Close Profile Complete
B04 = 0 Normal
= 1 Injection Profile Complete
B05 = 0 Normal
= 1 Pack Profile Complete
B06 = 0 Normal
= 1 Hold Profile Complete
B07 = 0 Normal
= 1 Pre-decompression Movement Complete
B08 = 0 Normal
= 1 Plastication Profile Complete
B09 = 0 Normal
= 1 Post-decompression Movement Complete
B10 = 0 Normal
= 1 First Clamp Open Profile Complete
B11 = 0 Normal
= 1 Second Clamp Open Profile Complete
B12 = 0 Normal
= 1 Third Clamp Open Profile Complete
B13 = 0 Normal
= 1 Clamp Open Slow Profile Complete
B14 = 0 Normal
= 1 Ejector Profile Complete
Module Busy Status
B15 = 0 Normal
= 1 No Action in Progress
The module resets this bit when it is performing one of the following:
S
executing a profile or decompression movement
S
holding its outputs at any End of phase values
S
executing any jog movement
