3–25Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
RLS
Hold Profile ERC Actuals
Word Description
RLS25 Hold Segment 1
RLS26 Hold Segment 2
RLS27 Hold Segment 3
RLS28 Hold Segment 4
RLS29 Hold Segment 5
Plastication Profile ERC Actuals
Word Description
RLS30 Plastication Segment 1
RLS31 Plastication Segment 2
RLS32 Plastication Segment 3
RLS33 Plastication Segment 4
RLS34 Plastication Segment 5
RLS35 Plastication Segment 6
RLS36 Plastication Segment 7
RLS37 Plastication Segment 8
RLS38 Plastication Segment 9
RLS39 Plastication Segment 10
RLS40 Plastication Segment 11
RLS41 - 64 Open
Bit-mapped Status Words
Word Bit Description
SYS01
B00-B07 Block ID = 00000001
B08-B15 Power-up Status
B08 = 0 The module Wants Complete Download
= 1 Valid MCC on Board
Jog Execution Status
B09 = 0 Normal
= 1 Executing Screw Rotate Jog
The module sets this bit when responding to command bit DYC01-B09 = 1 and sets its outputs to JGC09 – JGC16.
B10 = 0 Normal
= 1 Executing Ram (Screw) Jog Forward
The module sets this bit when responding to command bit DYC01-B10 = 1 and sets its outputs to JGC17 – JGC24.
B11 = 0 Normal
= 1 Executing Ram (Screw) Jog Reverse
The module sets this bit when responding to command bit DYC01-B11 = 1 and sets its outputs to JGC25 – JGC32.
B12 = 0 Normal
= 1 Executing Clamp Jog Forward
The module sets this bit when responding to command bit DYC01-B12 = 1 and sets its outputs to JGC33 – JGC40.
B13 = 0 Normal
= 1 Executing Clamp Jog Reverse
The module sets this bit when responding to command bit DYC01-B13 = 1 and sets its outputs to JGC41 – JGC48.
B14 = 0 Normal
= 1 Executing Ejector Jog Advance
The module sets this bit when responding to command bit DYC01-B14 = 1 and sets its outputs to JGC49 – JGC56.
B15 = 0 Normal
= 1 Executing Ejector Jog Retract
The module sets this bit when responding to command bit DYC01-B15 = 1 and sets its outputs to JGC57 – JGC64.
SYS – System Status Block
