3–24 Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
PTS40 Plastication Segment 4 starting data point
PTS41 Plastication Segment 5 starting data point
PTS42 Plastication Segment 6 starting data point
PTS43 Plastication Segment 7 starting data point
PTS44 Plastication Segment 8 starting data point
PTS45 Plastication Segment 9 starting data point
PTS46 Plastication Segment 10 starting data point
PTS47 Plastication Segment 11 starting data point
PTS48 Post-decompress starting data point
PTS49 - 64 Open
Bit-mapped Status Words
Word Description
RLS01 Block ID = 00001000 (Low byte). High byte identical to SYS01
RLS02 See SYS02
RLS03 See SYS03
RLS04 See SYS04
RLS05 - 08 Open
Injection Profile ERC Actuals
Word Description
RLS09 Injection Segment 1
RLS10 Injection Segment 2
RLS11 Injection Segment 3
RLS12 Injection Segment 4
RLS13 Injection Segment 5
RLS14 Injection Segment 6
RLS15 Injection Segment 7
RLS16 Injection Segment 8
RLS17 Injection Segment 9
RLS18 Injection Segment 10
RLS19 Injection Segment 11
Pack Profile ERC Actuals
Word Description
RLS20 Pack Segment 1
RLS21 Pack Segment 2
RLS22 Pack Segment 3
RLS23 Pack Segment 4
RLS24 Pack Segment 5
RLS – Inject ERC Values
Status Block
