User Manual

1–2 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
CLC01 B37:40 Block ID 00000000 00011011
CLC02-04 B37:41-43 RFU
ERC Values for Clamp Close Profiles
CLC05-08 N43:601-604 RFU
CLC09 N43:605 Segment 1 (first clamp close)
CLC10 N43:606 Segment 2 (first clamp close)
CLC11 N43:607 Segment 3 (first clamp close)
CLC12 N43:608 Segment 4 (second clamp close)
CLC13 N43:609 Segment 5 (second clamp close)
CLC14 N43:610 Segment 6 (second clamp close)
CLC15 N43:611 Segment 7 (third clamp close)
CLC16 N43:612 Segment 8 (third clamp close)
CLC17 N43:613 Segment 9 (third clamp close)
CLC18 N43:614 Segment 1 (clamp LPC)
CLC19 N43:615 Segment 2 (clamp LPC)
ERC Values for Clamp Open Profiles
CLC20 N43:616 Segment 1 (first clamp open)
CLC21 N43:617 Segment 2 (first clamp open)
CLC22 N43:618 Segment 3 (first clamp open)
CLC23 N43:619 Segment 4 (second clamp open)
CLC24 N43:620 Segment 5 (second clamp open)
CLC25 N43:621 Segment 6 (second clamp open)
CLC26 N43:622 Segment 7 (third clamp open)
CLC27 N43:623 Segment 8 (third clamp open)
CLC28 N43:624 Segment 9 (third clamp open)
CLC29 N43:625 Segment 1 (clamp open slow)
CLC30 N43:626 Segment 2 (clamp open slow)
ERC Values for Ejector Profiles
CLC31 N43:627 Segment 1 (full advance)
CLC32 N43:628 Segment 2 (full advance)
CLC33 N43:629 Segment 3 (full advance)
CLC34 N43:630 RFU
CLC35 N43:631 Tip retract segment
CLC36 N43:632 RFU
CLC37 N43:633 Tip advance segment
CLC38 N43:634 RFU
CLC39 N43:635 Segment 1 (full retract)
CLC40 N43:636 Segment 2 (full retract)
CLC41 N43:637 Segment 3 (full retract)
ERC Values for Ejector Profiles
CLC42-64 N43:638-660 RFU
CLC – Clamp and Eject
ERC Values Block
