3–23Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
PTS
Word Bit Description
B03 Block contains trace #2 data
B04 Block contains trace #3 data
B05 Block contains trace #4 data
B06 - B14 Open
B15 Block contains phase/segment start information
PTS06 Trace data block number
B00 Block contains trace data points 1 to 50
B01 Block contains trace data points 51 to 100
B02 Block contains trace data points 101 to 150
B03 Block contains trace data points 151 to 200
B04 Block contains trace data points 201 to 250
B05 Block contains trace data points 251 to 300
B06 Block contains trace data points 301 to 350
B07 Block contains trace data points 351 to 400
B08 - B15 Reserved
PTS07, 08 Open
PTS09 Reports the time (in hundredths of seconds) after injection starts until the first trace data point is recorded.
PTS10 Reports how many data points (0 to 400) have been collected for the trace indicated in PTS05 and PTS06.
This value will not exceed the last data point for the block indicated in PTS06.
PTS11 - 14 Open
PTS15 Injection Segment 1 starting data point
If one of PTS05-B01 to -B05 is set, PTS15 to PTS64 contain trace data. If PTS05-B15 is set, PTS15 to PTS48 contain
phase/segment start information. Each word contains starting data point (1 - 400) for the listed phase or segment.
If the phase or segment was not executed, this value will be zero.
PTS16 Injection Segment 2 starting data point
PTS17 Injection Segment 3 starting data point
PTS18 Injection Segment 4 starting data point
PTS19 Injection Segment 5 starting data point
PTS20 Injection Segment 6 starting data point
PTS21 Injection Segment 7 starting data point
PTS22 Injection Segment 8 starting data point
PTS23 Injection Segment 9 starting data point
PTS24 Injection Segment 10 starting data point
PTS25 Injection Segment 11 starting data point
PTS26 Pack Segment 1 starting data point
PTS27 Pack Segment 2 starting data point
PTS28 Pack Segment 3 starting data point
PTS29 Pack Segment 4 starting data point
PTS30 Pack Segment 5 starting data point
PTS31 Hold Segment 1 starting data point
PTS32 Hold Segment 2 starting data point
PTS33 Hold Segment 3 starting data point
PTS34 Hold Segment 4 starting data point
PTS35 Hold Segment 5 starting data point
PTS36 Pre-decompress starting data point
PTS37 Plastication Segment 1 starting data point
PTS38 Plastication Segment 2 starting data point
PTS39 Plastication Segment 3 starting data point
