Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Open Profile Execution Times
Word Description
OPS57 First Clamp Open Profile Execution Time [21] Total time required for last profile.
OPS58 Second Clamp Open Profile Execution Time [21] Total time required for last profile.
OPS59 Third Clamp Open Profile Execution Time [21] Total time required for last profile.
OPS60 Clamp Open Slow Profile Execution Time [21] Total time required for last profile.
OPS61 - 64 Open
Bit-mapped Status Words
Word Bit Description
PPS01 Block ID = 00000101 (Low byte). High byte identical to SYS01
PPS02 See SYS02
PPS03 See SYS03
PPS04 See SYS04
PPS05 Open
PPS06 Open
PPS07 CV High Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
maximum (100%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to maximum (100%).
When this bit
is latched ON:
algorithm CV
is maximum during:
B00 Segment 1
B01 Segment 2
B02 Segment 3
B03 Segment 4
B04 Segment 5
B05 Segment 6
B06 Segment 7
B07 Segment 8
B08 Segment 9
B09 Segment 10
B10 Segment 11
B11-B15 Open
PPS08 CV Low Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
minimum (0%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to minimum (0%).
When this bit
is latched ON:
algorithm CV
is minimum during:
B00 Segment 1
B01 Segment 2
B02 Segment 3
B03 Segment 4
B04 Segment 5
B05 Segment 6
PPS – Plastication Profile
Status Block
