User Manual

3–19Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
OPS
Third Clamp Open Profile Actuals
Word Description
OPS27 Actual Segment 7 Velocity [07] or [08] Average clamp velocity during last Segment 7.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS28 Actual Segment 7 Pressure [02] Average clamp pressure during last Segment 7.
OPS29 Actual Segment 7 Execution Time [21] Time required for last Segment 7.
OPS30 Actual Segment 8 Velocity [07] or [08] Average clamp velocity during last Segment 8.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS31 Actual Segment 8 Pressure [02] Average clamp pressure during last Segment 8.
OPS32 Actual Segment 8 Execution Time [21] Time required for last Segment 8.
OPS33 Actual Segment 9 Velocity [07] or [08] Average clamp velocity during last Segment 9.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS34 Actual Segment 9 Pressure [02] Average clamp pressure during last Segment 9.
OPS35 Actual Segment 9 Execution Time [21] Time required for last Segment 9.
Clamp Open Slow Profile Actuals
Word Description
OPS36 Actual Segment 1 Velocity [07] or [08] Average clamp velocity during last Segment 1.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS37 Actual Segment 1 Pressure [02] Average clamp pressure during last Segment 1.
OPS38 Actual Segment 1 Execution Time [21] Time required for last Segment 1.
OPS39 Actual Segment 2 Velocity [07] or [08] Average clamp velocity during last Segment 2.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS40 Actual Segment 2 Pressure [02] Average clamp pressure during last Segment 2.
OPS41 Actual Segment 2 Execution Time [21] Time required for last Segment 2.
OPS42 Velocity at Start-of Clamp Open Slow Profile [07] or [08] Instantaneous clamp velocity at start of last profile.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS43 Pressure at Start-of Clamp Open Slow Profile [02] Instantaneous clamp pressure at start of last profile.
OPS44 Position at Start-of Clamp Open Slow Profile [14] Instantaneous clamp position at start of last profile.
OPS45 Velocity at End of Clamp Open Slow Profile [07] or [08] Instantaneous clamp velocity at completion of last profile.
If OPC03-B14 is RESET, the module reports this average in percent velocity.
If OPC03-B14 is SET, it reports it in in.(mm)/s.
OPS46 Pressure at End of Clamp Open Slow Profile [02] Instantaneous clamp pressure at completion of last profile.
OPS47 Position at End of Clamp Open Slow Profile [14] Instantaneous clamp position at completion of last profile.
OPS48 - 52 Open
Open Profile Maximum Pressures
Word Description
OPS53 Maximum Pressure During First Clamp Open Profile [02] Maximum instantaneous clamp pressure during last profile.
OPS54 Maximum Pressure During Second Clamp Open Profile [02] Maximum instantaneous clamp pressure during last profile.
OPS55 Maximum Pressure During Third Clamp Open Profile [02] Maximum instantaneous clamp pressure during last profile.
OPS56 Maximum Pressure During Clamp Open Slow Profile [02] Maximum instantaneous clamp pressure during last profile.
