3–13Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
HPS
Hold Profile Actuals
Word Description
HPS26 Actual Hold Segment 1 Cavity Pressure [04] Average cavity pressure during last Segment 1.
HPS27 Actual Hold Segment 1 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 1.
HPS28 Actual Hold End of Segment 1 Position [12] Ram (Screw) position at completion of last Segment 1.
HPS29 Actual Hold Segment 2 Cavity Pressure [04] Average cavity pressure during last Segment 2.
HPS30 Actual Hold Segment 2 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 2.
HPS31 Actual Hold End of Segment 2 Position [12] Ram (Screw) position at completion of last Segment 2.
HPS32 Actual Hold Segment 3 Cavity Pressure [04] Average cavity pressure during last Segment 3.
HPS33 Actual Hold Segment 3 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 3.
HPS34 Actual Hold End of Segment 3 Position [12] Ram (Screw) position at completion of last Segment 3.
HPS35 Actual Hold Segment 4 Cavity Pressure [04] Average cavity pressure during last Segment 4.
HPS36 Actual Hold Segment 4 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 4
HPS37 Actual Hold End of Segment 4 Position [12] Ram (Screw) position at completion of last Segment 4.
HPS38 Actual Hold Segment 5 Cavity Pressure [04] Average cavity pressure during last Segment 5.
HPS39 Actual Hold Segment 5 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 5.
HPS40 Actual Hold End of Segment 5 Position [12] Ram (Screw) position at completion of last Segment 5
HPS41 - 50 Open
Pack Maximum Pressures
Word Description
HPS51 Maximum Ram (Screw) Pressure During Pack [01] Maximum instantaneous ram (screw) pressure during last profile.
HPS52 Maximum Cavity Pressure During Pack [04] Maximum instantaneous cavity pressure during last profile.
Hold Maximum Pressures
Word Description
HPS53 Maximum Ram (Screw) Pressure During Hold [01] Maximum instantaneous ram (screw) pressure during last profile.
HPS54 Maximum Cavity Pressure During Hold [04] Maximum instantaneous cavity pressure during last profile.
Pre-decompression Maximum Pressure
Word Description
HPS55 Maximum Ram (Screw) Pressure During Pre-decompression [01] Max instantaneous ram (screw) pressure during last movement.
HPS56 Open
Execution Times
Word Description
HPS57 Pack Profile Execution Time [21] Total time required for last profile.
HPS58 Hold Profile Execution Time [21] Total time required for last profile.
HPS59 Pre-decompression Movement Execution Time [21] Total time required for last movement.
HPS60 Open
Pre-decompression Movement Actuals
Word Description
HPS61 Pre-decompression Movement Actual Velocity [06] Average ram (screw) velocity during last movement, reported in in.(mm)/s.
HPS62 Pre-decompression Movement Actual Pressure [01] Average ram (screw) pressure during last movement.
End of Hold Ram (Screw) Position
Word Bit Description
HPS63 Position at End of Hold [12] Instantaneous ram (screw) position at completion of last profile.
HPS64 Open
