3–9Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
EPS
Close Profile Execution Times
Word Description
CPS57 First Clamp Close Profile Execution Time [21] Total time required for last profile.
CPS58 Second Clamp Close Profile Execution Time [21] Total time required for last profile.
CPS59 Third Clamp Close Profile Execution Time [21] Total time required for last profile.
CPS60 Clamp Low Pressure Close Profile Execution Time [21] Total time required for last profile.
CPS61 - 64 Open
Bit-mapped Status Words
Word Bit Description
EPS01 Block ID = 00000111 (Low byte). High byte identical to SYS01
EPS01 See SYS01
EPS02 See SYS02
EPS03 See SYS03
EPS04 See SYS04
EPS05 Open
EPS06 Open
EPS07 CV High Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
maximum (100%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to maximum (100%).
When this bit
is latched ON:
algorithm CV
is maximum during:
B00 Full Advance Segment 1
B01 Full Advance Segment 2
B02 Full Advance Segment 3
B03 Open
B04 Tip Retract Segment
B05 Open
B06 Tip Advance Segment
B07 Open
B08 Full Retract Segment 1
B09 Full Retract Segment 2
B10 Full Retract Segment 3
B11-B15 Open
EPS08 CV Low Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
minimum (0%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to minimum (0%).
When this bit
is latched ON:
algorithm CV
is minimum during:
B00 Full Advance Segment 1
B01 Full Advance Segment 2
B02 Full Advance Segment 3
B03 Open
B04 Tip Retract Segment
B05 Open
EPS – Ejector Profile
Status Block
