3–8 Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Third Clamp Close Profile Actuals
Word Description
CPS27 Actual Segment 7 Velocity [07] or [08] Average clamp velocity during last Segment 7.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS28 Actual Segment 7 Pressure [02] Average clamp pressure during last Segment 7.
CPS29 Actual Segment 7 Execution Time [21] Time required for last Segment 7.
CPS30 Actual Segment 8 Velocity [07] or [08] Average clamp velocity during last Segment 8.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS31 Actual Segment 8 Pressure [02] Average clamp pressure during last Segment 8.
CPS32 Actual Segment 8 Execution Time [21] Time required for last Segment 8.
CPS33 Actual Segment 9 Velocity [07] or [08] Average clamp velocity during last Segment 9.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS34 Actual Segment 9 Pressure [02] Average clamp pressure during last Segment 9.
CPS35 Actual Segment 9 Execution Time [21] Time required for last Segment 9.
Clamp Low Pressure Close Profile Actuals
Word Description
CPS36 Reserved
CPS37 Actual Segment 1 Pressure [02] Average clamp pressure during last Segment 1.
CPS38 Actual Segment 1 Execution Time [21] Time required for last Segment 1.
CPS39 Reserved
CPS40 Actual Segment 2 Pressure [02] Average clamp pressure during last Segment 2.
CPS41 Actual Segment 2 Execution Time [21] Time required for last Segment 2.
CPS42 Velocity at Start-of Clamp Low Press Close Profile [07] or [08] Instantaneous clamp velocity at start of last profile.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS43 Pressure at Start-of Clamp Low Pressure Close Profile [02] Instantaneous clamp pressure at start of last profile.
CPS44 Position at Start-of Clamp Low Pressure Close Profile [14] Instantaneous clamp position at start of last profile.
CPS45 Velocity at End of Clamp Low Pressure Close Profile [07] or [08] Instantaneous clamp velocity at completion of last profile.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS46 Pressure at End of Clamp Low Pressure Close Profile [02] Instantaneous clamp pressure at completion of last profile.
CPS47 Position at End of Clamp Low Pressure Close Profile [14] Instantaneous clamp position at completion of last profile.
CPS48 - 52 Open
Close Profile Maximum Pressures
Word Description
CPS53 Maximum Pressure During First Clamp Close Profile [02] Maximum instantaneous clamp pressure during last profile.
CPS54 Maximum Pressure During Second Clamp Close Profile [02]Maximum instantaneous clamp pressure during last profile.
CPS55 Maximum Pressure During Third Clamp Close Profile [02] Maximum instantaneous clamp pressure during last profile.
CPS56 Maximum Pressure During Clamp Low Pressure Close Profile [02] Maximum instantaneous clamp pressure during last profile.
