3–7Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
CPS
Word Bit Description
B04 Segment 5 (Second Clamp Close)
B05 Segment 6 (Second Clamp Close)
B06 Segment 7 (Third Clamp Close)
B07 Segment 8 (Third Clamp Close)
B08 Segment 9 (Third Clamp Close)
B09 Segment 1 (Clamp Low Pressure Close)
B10 Segment 2 (Clamp Low Pressure Close)
B11-B15 Open
First Clamp Close Profile Actuals
Word Description
CPS09 Actual Segment 1 Velocity [07] or [08] Average clamp velocity during last Segment 1.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS10 Actual Segment 1 Pressure [02] Average clamp pressure during last Segment 1.
CPS11 Actual Segment 1 Execution Time [21] Time required for last Segment 1.
CPS12 Actual Segment 2 Velocity [07] or [08] Average clamp velocity during last Segment 2.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS13 Actual Segment 2 Pressure [02] Average clamp pressure during last Segment 2.
CPS14 Actual Segment 2 Execution Time [21] Time required for last Segment 2.
CPS15 Actual Segment 3 Velocity [07] or [08] Average clamp velocity during last Segment 3.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS16 Actual Segment 3 Pressure [02] Average clamp pressure during last Segment 3.
CPS17 Actual Segment 3 Execution Time [21] Time required for last Segment 3.
Second Clamp Close Profile Actuals
Word Description
CPS18 Actual Segment 4 Velocity [07] or [08] Average clamp velocity during last Segment 4.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS19 Actual Segment 4 Pressure [02] Average clamp pressure during last Segment 4.
CPS20 Actual Segment 4 Execution Time [21] Time required for last Segment 4.
CPS21 Actual Segment 5 Velocity [07] or [08] Average clamp velocity during last Segment 5.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS22 Actual Segment 5 Pressure [02] Average clamp pressure during last Segment 5.
CPS23 Actual Segment 5 Execution Time [21] Time required for last Segment 5.
CPS24 Actual Segment 6 Velocity [07] or [08] Average clamp velocity during last Segment 6.
If CPC03-B14 is RESET, the module reports this average in percent velocity.
If CPC03-B14 is SET, it reports it in in.(mm)/s.
CPS25 Actual Segment 6 Pressure [02] Average clamp pressure during last Segment 6.
CPS26 Actual Segment 6 Execution Time [21] Time required for last Segment 6.
