3–6 Status Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
CLS37 Ejector Tip Advance Segment
CLS38 Reserved
CLS39 Ejector Full Retract Segment 1
CLS40 Ejector Full Retract Segment 2
CLS41 Ejector Full Retract Segment 3
CLS42 Reserved
CLS43 - 64 Open
Bit-mapped Status Words
Word Bit Description
CPS01 Block ID = 00000010 (Low byte). High byte identical to SYS01
CPS02 See SYS02
CPS03 See SYS03
CPS04 See SYS04
CPS05 Open
CPS06 Open
CPS07 CV High Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
maximum (100%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to maximum (100%).
When this bit
is latched ON:
algorithm CV
is maximum during:
B00 Segment 1 (First Clamp Close)
B01 Segment 2 (First Clamp Close)
B02 Segment 3 (First Clamp Close)
B03 Segment 4 (Second Clamp Close)
B04 Segment 5 (Second Clamp Close)
B05 Segment 6 (Second Clamp Close)
B06 Segment 7 (Third Clamp Close)
B07 Segment 8 (Third Clamp Close)
B08 Segment 9 (Third Clamp Close)
B09 Segment 1 (Clamp Low Pressure Close)
B10 Segment 2 (Clamp Low Pressure Close)
B11-B15 Open
CPS08 CV Low Limit Alarms
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
minimum (0%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to minimum (0%).
When this bit
is latched ON:
algorithm CV
is maximum during:
B00 Segment 1 (First Clamp Close)
B01 Segment 2 (First Clamp Close)
B02 Segment 3 (First Clamp Close)
B03 Segment 4 (Second Clamp Close)
CPS – Clamp Close
Profiles Status Block
