User Manual

3–4 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
The QDC module can return any of these status blocks:
Block Description
IPS Injection Profile Status Block
HPS Pack/Hold Profile Status Block
PPS Plastication Profile Status Block
PTS Process Trace Status Block
RLS Inject ERC Values Status Block
After you configure the QDC module with a valid MCC, the module
determines if it has access to ram (screw) position data from the ram
(screw) position sensor. The module considers these command blocks
recognizable and can return these status blocks when it has an analog
input reserved for a ram (screw) position sensor, and the sensor is
physically connected to input 1.
The QDC module can return any of these status blocks:
Block Description
CPS Clamp Close Profile Status Block
OPS Clamp Open Profile Status Block
CLS Clamp and Eject ERC Values Status Block
After you configure the QDC module with a valid MCC, the module
determines if it has access to clamp position data from the clamp
position sensor. The module considers these command blocks
recognizable and can return these status blocks when it has an analog
input reserved for a clamp position sensor, and the sensor is physically
connected to input 3.
The QDC module can return this status block:
Block Description
EPS Ejector Profile Status Block
After you configure the QDC module with a valid MCC, the module
determines if it has access to clamp and ejector position data from
both position sensors. The module considers these command blocks
recognizable and can return the status block when it has analog
inputs reserved for ejector position and clamp position sensors, and
both sensors are physically connected to inputs 3 and 4 respectively.
Status Blocks for
Reporting Ram (Screw)
Position
Status Blocks for
Reporting Clamp Position
Status Blocks for
Reporting Ejector Position
