2–109Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
TOC
Word Description
TOC13 Output #5 Set-output Value during Profile [19]
TOC14 Output #6 Set-output Value during Profile [19]
TOC15 Output #7 Set-output Value during Profile [19]
TOC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
between setpoints during the Third Clamp Open Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
TOC17 Output #1 Acceleration Ramp Rate during Profile [20]
TOC18 Output #2 Acceleration Ramp Rate during Profile [20]
TOC19 Output #3 Acceleration Ramp Rate during Profile [20]
TOC20 Output #4 Acceleration Ramp Rate during Profile [20]
TOC21 Output #5 Acceleration Ramp Rate during Profile [20]
TOC22 Output #6 Acceleration Ramp Rate during Profile [20]
TOC23 Output #7 Acceleration Ramp Rate during Profile [20]
TOC24 Output #8 Acceleration Ramp Rate during Profile [20]
TOC25 Output #1 Deceleration Ramp Rate during Profile [20]
TOC26 Output #2 Deceleration Ramp Rate during Profile [20]
TOC27 Output #3 Deceleration Ramp Rate during Profile [20]
TOC28 Output #4 Deceleration Ramp Rate during Profile [20]
TOC29 Output #5 Deceleration Ramp Rate during Profile [20]
TOC30 Output #6 Deceleration Ramp Rate during Profile [20]
TOC31 Output #7 Deceleration Ramp Rate during Profile [20]
TOC32 Output #8 Deceleration Ramp Rate during Profile [20]
End of Profile Set-output Values
When the module completes the Third Clamp Open Profile and
OPC03-B10 is set and SYS21-B14 is reset, it:
• sets its outputs to the values listed below
• sets status bit SYS22-B12
• ignores SYS22 and these values and gives output control to the
Ejector Profile if SYS21-B14 is set
• uses ramp rates TOC17 - 32 when changing outputs to these values
Use these values for pulling cores if applied before starting the
Clamp Open Slow Profile.
Word Description
TOC33 Output #1 Set-output Value at End of Profile [19]
TOC34 Output #2 Set-output Value at End of Profile [19]
TOC35 Output #3 Set-output Value at End of Profile [19]
TOC36 Output #4 Set-output Value at End of Profile [19]
