User Manual

2–106 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
TCC17 Output #1 Acceleration Ramp Rate during Profile [20]
TCC25 Output #1 Deceleration Ramp Rate during Profile [20]
TCC26 Output #2 Deceleration Ramp Rate during Profile [20]
TCC27 Output #3 Deceleration Ramp Rate during Profile [20]
TCC28 Output #4 Deceleration Ramp Rate during Profile [20]
TCC29 Output #5 Deceleration Ramp Rate during Profile [20]
TCC30 Output #6 Deceleration Ramp Rate during Profile [20]
TCC31 Output #7 Deceleration Ramp Rate during Profile [20]
TCC32 Output #8 Deceleration Ramp Rate during Profile [20]
End of Profile Set-output Values
When the module completes the Third Clamp Close Profile and
CPC03-B10 is set, it:
• sets its outputs to the following values
• sets status bit SYS22-B02
• uses ramp rates TCC17 - 32 when changing outputs to these values
Use these values for setting cores if applied before starting the
Clamp Low Pressure Close Profile.
Word Description
TCC33 Output #1 Set-output Value at End of Profile [19]
TCC34 Output #2 Set-output Value at End of Profile [19]
TCC35 Output #3 Set-output Value at End of Profile [19]
TCC36 Output #4 Set-output Value at End of Profile [19]
TCC37 Output #5 Set-output Value at End of Profile [19]
TCC38 Output #6 Set-output Value at End of Profile [19]
TCC39 Output #7 Set-output Value at End of Profile [19]
TCC40 Output #8 Set-output Value at End of Profile [19]
Pressure Control Limits
Word Description
TCC41 Pressure Minimum Control Limit [02] Minimum controllable clamp pressure attainable during any Press/Pos Third Clamp Close
Profile. The module expects this clamp pressure when setting its selected pressure valve to the %-output in TCC43.
TCC42 Pressure Maximum Control Limit [02] Maximum controllable clamp pressure attainable during any Press/Pos Third Clamp Close
Profile. The module expects this clamp pressure when setting its selected pressure valve to the %-output in TCC44.
TCC43 Selected Pressure Valve Output for Minimum [19] 0% CV output percentage that the module uses to drive the selected pressure
valve during any Press/Pos Third Clamp Close Profile. The module expects a pressure equal to TCC41 when setting the selected
pressure valve to this %-output during profile execution. The Press/Pos Third Clamp Close Profile will be executed as a reverse-act-
ing algorithm if this entry is greater than TCC44.
TCC44 Selected Pressure Valve Output for Maximum [19] 100% CV output percentage t hat the module uses to drive the selected pressure
valve during any Press/Pos Third Clamp Close Profile. The module expects a pressure equal to TCC42 when setting the selected
pressure valve to this %-output during profile execution. The Press/Pos Third Clamp Close Profile will be executed as a reverse-act-
ing algorithm if this entry is less than TCC43.
