User Manual

2–102 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Unselected Valve Set-output Values
When the module starts the Second Clamp Open Profile, it:
• sets its unselected outputs to the values listed below
• ignores the unselected value of the selected output
• uses ramp rates SOC17 - SOC32 to ramp unselected outputs
if then
the module is commanded to start the
Ejector Profile during this SOC Profile
this SOC Profile surrenders control of the
unselected valve that is the selected
Ejector Profile valve
the module is commanded to start this SOC
Profile during the Ejector Profile
the Ejector Profile gives control of all of its
unselected valves to this SOC Profile
Second Clamp Open and Ejector Profiles
are run concurrently
all outputs that are unselected in both
profiles are controlled by this SOC Profile
Word Description
SOC09 Output #1 Set-output Value during Profile [19]
SOC10 Output #2 Set-output Value during Profile [19]
SOC11 Output #3 Set-output Value during Profile [19]
SOC12 Output #4 Set-output Value during Profile [19]
SOC13 Output #5 Set-output Value during Profile [19]
SOC14 Output #6 Set-output Value during Profile [19]
SOC15 Output #7 Set-output Value during Profile [19]
SOC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
between setpoints during the Second Clamp Open Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
SOC17 Output #1 Acceleration Ramp Rate during Profile [20]
SOC18 Output #2 Acceleration Ramp Rate during Profile [20]
SOC19 Output #3 Acceleration Ramp Rate during Profile [20]
SOC20 Output #4 Acceleration Ramp Rate during Profile [20]
SOC21 Output #5 Acceleration Ramp Rate during Profile [20]
SOC22 Output #6 Acceleration Ramp Rate during Profile [20]
SOC23 Output #7 Acceleration Ramp Rate during Profile [20]
SOC24 Output #8 Acceleration Ramp Rate during Profile [20]
SOC25 Output #1 Deceleration Ramp Rate during Profile [20]
SOC26 Output #2 Deceleration Ramp Rate during Profile [20]
SOC27 Output #3 Deceleration Ramp Rate during Profile [20]
SOC28 Output #4 Deceleration Ramp Rate during Profile [20]
SOC29 Output #5 Deceleration Ramp Rate during Profile [20]
SOC30 Output #6 Deceleration Ramp Rate during Profile [20]
SOC31 Output #7 Deceleration Ramp Rate during Profile [20]
SOC32 Output #8 Deceleration Ramp Rate during Profile [20]
