2–98 Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word
Bit Description
SCC02 B03 Open
B04-B06 Selected Pressure Control Valve
The module uses its algorithm to drive the following output during any Press/Pos Second Clamp Close Profile.
B06 B05 B04
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
B07 Pressure Algorithm Selection
= 0 Dependent Gains (ISA)
= 1 Independent Gains (A-B)
B08 - B15 Open
SCC03 - 04 Open
Expert Response Compensation (ERC) Percentage
Word Description
SCC05 Minimum Velocity Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
SCC06 Minimum Pressure Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
SCC07 Open
Watchdog Timer
Word Description
SCC08 Profile Watchdog Timer Preset [21] When the module starts the Second Clamp Close Profile, it
S
starts an internal Profile Watchdog timer
S
stops this timer and resets its accumulated value to zero (after reporting total execution time in CPS58) when it completes the
profile
S
sets master status bit SYS04-B01 when the accumulated value of this timer equals or exceeds this entry
A zero entry inhibits SYS04-B01.
Unselected Valve Set-output Values
When the module starts the Second Clamp Close Profile, it:
• sets its unselected outputs to the values listed below
• ignores the unselected value of the selected output
• uses ramp rates SCC17 - SCC32 to ramp unselected outputs
Word Description
SCC09 Output #1 Set-output Value during Profile [19]
SCC10 Output #2 Set-output Value during Profile [19]
SCC11 Output #3 Set-output Value during Profile [19]
SCC12 Output #4 Set-output Value during Profile [19]
SCC13 Output #5 Set-output Value during Profile [19]
SCC14 Output #6 Set-output Value during Profile [19]
SCC15 Output #7 Set-output Value during Profile [19]
SCC16 Output #8 Set-output Value during Profile [19]
