2–97Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
RLC
Pack Profile ERC Values
Word Description
RLC20 Pack Segment 1
RLC21 Pack Segment 2
RLC22 Pack Segment 3
RLC23 Pack Segment 4
RLC24 Pack Segment 5
Hold Profile ERC Values
Word Description
RLC25 Hold Segment 1
RLC26 Hold Segment 2
RLC27 Hold Segment 3
RLC28 Hold Segment 4
RLC29 Hold Segment 5
Plastication Profile ERC Values
Word Description
RLC30 Plastication Segment 1
RLC31 Plastication Segment 2
RLC32 Plastication Segment 3
RLC33 Plastication Segment 4
RLC34 Plastication Segment 5
RLC35 Plastication Segment 6
RLC36 Plastication Segment 7
RLC37 Plastication Segment 8
RLC38 Plastication Segment 9
RLC39 Plastication Segment 10
RLC40 Plastication Segment 11
RLC41 - 64 Open
Bit-mapped Control Words
Word Bit Description
SCC01 Block ID = 00000100 (Low byte). High byte reserved for the module. Do not use.
SCC02 Configuration Selections
B00-B02 Selected Velocity Control Valve
The module uses its algorithm to drive the following output during any Vel/Pos Second Clamp Close Profile.
B02 B01 B00
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
SCC – Second Clamp
Close Configuration Block
