2–96 Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
PTC10 Trace #3 selection
B01 Injection position
B02 Injection pressure
B03 Injection velocity
The module will return unscaled injection position data if injection velocity is selected. The process trace screen uses
this position information to calculate and display velocity.
B04 Cavity pressure
B05 Screw RPM
B06 Injection flow valve output
B07 Injection pressure valve output
B08 - B15 Reserved Do not use.
PTC11 Trace #4 selection
B01 Injection position
B02 Injection pressure
B03 Injection velocity
The module will return unscaled injection position data if injection velocity is selected. The process trace screen uses
this position information to calculate and display velocity.
B04 Cavity pressure
B05 Screw RPM
B06 Injection flow valve output
B07 Injection pressure valve output
B08 - B15 Reserved Do not use.
PTC12 - 64 Open
Bit-mapped Control Words
Word Description
RLC01 Block ID = 00011010 (Low byte). High byte reserved for the module. Do not use.
RLC02 - 08 Open
Injection Profile ERC Values
Word Description
RLC09 Injection Segment 1
RLC10 Injection Segment 2
RLC11 Injection Segment 3
RLC12 Injection Segment 4
RLC13 Injection Segment 5
RLC14 Injection Segment 6
RLC15 Injection Segment 7
RLC16 Injection Segment 8
RLC17 Injection Segment 9
RLC18 Injection Segment 10
RLC19 Injection Segment 11
RLC – Inject ERC Values
Block
