2–94 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
PSC13 Output #5 Set-output Value during Movement [19]
PSC14 Output #6 Set-output Value during Movement [19]
PSC15 Output #7 Set-output Value during Movement [19]
PSC16 Output #8 Set-output Value during Movement [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
between setpoints during Post-decompression Movement. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
PSC17 Output #1 Acceleration Ramp Rate during Movement [20]
PSC18 Output #2 Acceleration Ramp Rate during Movement [20]
PSC19 Output #3 Acceleration Ramp Rate during Movement [20]
PSC20 Output #4 Acceleration Ramp Rate during Movement [20]
PSC21 Output #5 Acceleration Ramp Rate during Movement [20]
PSC22 Output #6 Acceleration Ramp Rate during Movement [20]
PSC23 Output #7 Acceleration Ramp Rate during Movement [20]
PSC24 Output #8 Acceleration Ramp Rate during Movement [20]
PSC25 Output #1 Deceleration Ramp Rate during Movement [20]
PSC26 Output #2 Deceleration Ramp Rate during Movement [20]
PSC27 Output #3 Deceleration Ramp Rate during Movement [20]
PSC28 Output #4 Deceleration Ramp Rate during Movement [20]
PSC29 Output #5 Deceleration Ramp Rate during Movement [20]
PSC30 Output #6 Deceleration Ramp Rate during Movement [20]
PSC31 Output #7 Deceleration Ramp Rate during Movement [20]
PSC32 Output #8 Deceleration Ramp Rate during Movement [20]
End of Movement Set-output Values
When the module completes the Post-decompression Movement, it:
• sets its outputs to the following values
• sets status bit SYS22-B09
• uses ramp rates PSC17 - 32 when changing outputs to these values
Use these values for-pulling cores if applied before starting the first
clamp open profile.
Word Description
PSC33 Output #1 Set-output Value at End of Movement [19]
PSC34 Output #2 Set-output Value at End of Movement [19]
PSC35 Output #3 Set-output Value at End of Movement [19]
PSC36 Output #4 Set-output Value at End of Movement [19]
PSC37 Output #5 Set-output Value at End of Movement [19]
PSC38 Output #6 Set-output Value at End of Movement [19]
PSC39 Output #7 Set-output Value at End of Movement [19]
PSC40 Output #8 Set-output Value at End of Movement [19]
PSC41 - 56 Open
