Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word
Description
PRC09 Output #1 Set-output Value during Movement [19]
PRC10 Output #2 Set-output Value during Movement [19]
PRC11 Output #3 Set-output Value during Movement [19]
PRC12 Output #4 Set-output Value during Movement [19]
PRC13 Output #5 Set-output Value during Movement [19]
PRC14 Output #6 Set-output Value during Movement [19]
PRC15 Output #7 Set-output Value during Movement [19]
PRC16 Output #8 Set-output Value during Movement [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Pre-decompression Movement.
The module interprets a ramp rate entry of zero as a step function
ramp (ramp disable).
Word Description
PRC17 Output #1 Acceleration Ramp Rate during Movement [20]
PRC18 Output #2 Acceleration Ramp Rate during Movement [20]
PRC19 Output #3 Acceleration Ramp Rate during Movement [20]
PRC20 Output #4 Acceleration Ramp Rate during Movement [20]
PRC21 Output #5 Acceleration Ramp Rate during Movement [20]
PRC22 Output #6 Acceleration Ramp Rate during Movement [20]
PRC23 Output #7 Acceleration Ramp Rate during Movement [20]
PRC24 Output #8 Acceleration Ramp Rate during Movement [20]
PRC25 Output #1 Deceleration Ramp Rate during Movement [20]
PRC26 Output #2 Deceleration Ramp Rate during Movement [20]
PRC27 Output #3 Deceleration Ramp Rate during Movement [20]
PRC28 Output #4 Deceleration Ramp Rate during Movement [20]
PRC29 Output #5 Deceleration Ramp Rate during Movement [20]
PRC30 Output #6 Deceleration Ramp Rate during Movement [20]
PRC31 Output #7 Deceleration Ramp Rate during Movement [20]
PRC32 Output #8 Deceleration Ramp Rate during Movement [20]
End of Movement Set-output Values
When the module completes the Pre-decompression Movement and
HPC03-B09 is SET, it:
• sets its outputs to the following values
• sets status bit SYS22-B07
• uses ramp rates PRC17 - 32 when changing outputs to these values
Word Description
PRC33 Output #1 Set-output Value at End of Movement [19]
PRC34 Output #2 Set-output Value at End of Movement [19]
PRC35 Output #3 Set-output Value at End of Movement [19]
PRC36 Output #4 Set-output Value at End of Movement [19]
