Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Unselected Valve Set-output Values
When the module starts the Plastication Profile, it:
• sets its unselected outputs to the values listed below
• ignores the unselected value of the selected output
• uses ramp rates PLC17 - PLC32 to ramp unselected outputs
Word Description
PLC09 Output #1 Set-output Value during Profile [19]
PLC10 Output #2 Set-output Value during Profile [19]
PLC11 Output #3 Set-output Value during Profile [19]
PLC12 Output #4 Set-output Value during Profile [19]
PLC13 Output #5 Set-output Value during Profile [19]
PLC14 Output #6 Set-output Value during Profile [19]
PLC15 Output #7 Set-output Value during Profile [19]
PLC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Plastication Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
PLC17 Output #1 Acceleration Ramp Rate during Profile [20]
PLC18 Output #2 Acceleration Ramp Rate during Profile [20]
PLC19 Output #3 Acceleration Ramp Rate during Profile [20]
PLC20 Output #4 Acceleration Ramp Rate during Profile [20]
PLC21 Output #5 Acceleration Ramp Rate during Profile [20]
PLC22 Output #6 Acceleration Ramp Rate during Profile [20]
PLC23 Output #7 Acceleration Ramp Rate during Profile [20]
PLC24 Output #8 Acceleration Ramp Rate during Profile [20]
PLC25 Output #1 Deceleration Ramp Rate during Profile [20]
PLC26 Output #2 Deceleration Ramp Rate during Profile [20]
PLC27 Output #3 Deceleration Ramp Rate during Profile [20]
PLC28 Output #4 Deceleration Ramp Rate during Profile [20]
PLC29 Output #5 Deceleration Ramp Rate during Profile [20]
PLC30 Output #6 Deceleration Ramp Rate during Profile [20]
PLC31 Output #7 Deceleration Ramp Rate during Profile [20]
PLC32 Output #8 Deceleration Ramp Rate during Profile [20]
End of Profile Set-output Values
When the module completes the Plastication Profile and PPC03-B08
is set, it:
• sets its outputs to the following values
• sets status bit SYS22-B08
• uses ramp rates PLC17 - 32 when changing outputs to these values
