2–83Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
PKC
Expert Response Compensation (ERC) Percentage
Word Description
PKC05 Minimum Cav Press Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
PKC06 Minimum Ram Press Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
PKC07 - 08 Open
Unselected Valve Set-output Values
When the module starts the Pack Profile, it:
• sets its unselected outputs to the values listed below
• ignores the unselected value of the selected output
• uses ramp rates PKC17 - PKC32 to ramp unselected outputs
Word Description
PKC09 Output #1 Set-output Value during Profile [19]
PKC10 Output #2 Set-output Value during Profile [19]
PKC11 Output #3 Set-output Value during Profile [19]
PKC12 Output #4 Set-output Value during Profile [19]
PKC13 Output #5 Set-output Value during Profile [19]
PKC14 Output #6 Set-output Value during Profile [19]
PKC15 Output #7 Set-output Value during Profile [19]
PKC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Pack Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
PKC17 Output #1 Acceleration Ramp Rate during Profile [20]
PKC18 Output #2 Acceleration Ramp Rate during Profile [20]
PKC19 Output #3 Acceleration Ramp Rate during Profile [20]
PKC20 Output #4 Acceleration Ramp Rate during Profile [20]
PKC21 Output #5 Acceleration Ramp Rate during Profile [20]
PKC22 Output #6 Acceleration Ramp Rate during Profile [20]
PKC23 Output #7 Acceleration Ramp Rate during Profile [20]
PKC24 Output #8 Acceleration Ramp Rate during Profile [20]
PKC25 Output #1 Deceleration Ramp Rate during Profile [20]
PKC26 Output #2 Deceleration Ramp Rate during Profile [20]
PKC27 Output #3 Deceleration Ramp Rate during Profile [20]
PKC28 Output #4 Deceleration Ramp Rate during Profile [20]
PKC29 Output #5 Deceleration Ramp Rate during Profile [20]
PKC30 Output #6 Deceleration Ramp Rate during Profile [20]
PKC31 Output #7 Deceleration Ramp Rate during Profile [20]
PKC32 Output #8 Deceleration Ramp Rate during Profile [20]
PKC33 - 40 Open
